Запчасти Komatsu WA500-7 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (COVER) (/8) ГИДРАВЛИКА

|$11

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

0

-1шт.

|$12

.PUMP SUBASSEMBLY (SEE FIG. H0210-01A0 )

1

-1шт.

|$2

708-1H-03250

COVER ASSEMBLY

1шт.

1

708-2G-14310

SCREW

1шт.

2

07000-B3038

O-RING

1шт.

3

708-2G-15230

RING, BACK-UP

1шт.

4

708-2L-35290

NUT

1шт.

5

708-2L-44130

COVER

1шт.

6

07000-B2050

O-RING

1шт.

7

708-2G-15310

RING

1шт.

8

01252-61645

BOLT

4шт.

|$13

11

-1шт.

|$14

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

12

-1шт.
