Запчасти Komatsu WA500-7 F-A ТРАНСМИССИЯ ФИЛЬТР. СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$13

TRANSMISSION (SEE FIG. F4300-06A0 )

0

-1шт.

|$14

.VALVE ASSEMBLY (SEE FIG. F4300-19A0 )

1

-1шт.

1

569-15-51721

FILTER ASSEMBLY

1шт.

2

569-15-51732

ELEMENT ASSEMBLY

1шт.

3

07000-A2060

O-RING

1шт.

4

07040-11812

PLUG

1шт.

5

07002-61823

O-RING

1шт.

6

01010-81080

BOLT

2шт.

7

01643-31032

WASHER

2шт.

8

07000-73022

O-RING

2шт.

9

700-11-31940

PLATE, NAME (LIMITED SUPPLY)

1шт.

|$15

11

-1шт.

|$16

F1 - SERVICEABLE PARTS LOCATED IN SERVICE KITS.

12

-1шт.

|$12

425-15-05750

SEAL KIT, TRANSMISSION CONTROL VALVE

1шт.

|$17

13

-1шт.

|$18

F2 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

14

-1шт.
