Запчасти Komatsu WA500-7 F-A ТРАНСМИССИЯ ECMV КЛАПАН СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$23

TRANSMISSION (SEE FIG. F4300-06A0 )

0

-1шт.

|$24

.VALVE ASSEMBLY (SEE FIG. F4300-19A0 )

1

-1шт.

1

425-15-45200

ECMV GROUP

6шт.

2

01252-90510

BOLT, HEXAGON SOCKET HEAD

4шт.

3

714-23-15690

BRACKET

1шт.

4

708-8E-16150

PLUG

1шт.

5

07002-61023

O-RING

1шт.

6

700-11-31940

PLATE, NAME (LIMITED SUPPLY)

1шт.

7

08034-00310

BAND, WHITE

1шт.

8

01252-A0650

BOLT, HEXAGON SOCKET HEAD

24шт.

9

08034-20519

STRAP, TIE

1шт.

10

56D-15-35800

ECMV ASSEMBLY

1шт.

11

01252-90510

BOLT, HEXAGON SOCKET HEAD

4шт.

12

425-15-35330

BRACKET

1шт.

13

700-11-31940

PLATE, NAME (LIMITED SUPPLY)

1шт.

14

708-8E-16150

PLUG

1шт.

15

07002-61023

O-RING

1шт.

16

01252-A0650

BOLT, HEXAGON SOCKET HEAD

4шт.

17

07000-72015

O-RING

28шт.

18

07000-71007

O-RING

7шт.

19

425-15-45150

BLOCK

1шт.

|$25

21

-1шт.

|$26

F1 - SERVICEABLE PARTS LOCATED IN SERVICE KITS.

22

-1шт.

|$22

425-15-05750

SEAL KIT, TRANSMISSION CONTROL VALVE

1шт.

|$27

23

-1шт.

|$28

F2 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

24

-1шт.
