Запчасти Komatsu WA500-6 ТРАНСМИССИЯ (4 И 3 КОЖУХ) F POWER TRANSMITTING СИСТЕМА

|$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$2

425-15-31001

TRANSMISSION ASSEMBLY

SN: H60358-UP

1шт.

|$3

0

TRANSMISSION ASSEMBLY

SN: H60051-H60357

1шт.

|$4

425-15-31011

TRANSMISSION ASSEMBLY, (WITH LOCK-UP)

SN: H60378-UP

1шт.

|$5

0

TRANSMISSION ASSEMBLY, (WITH LOCK-UP)

SN: H60051-H60377

1шт.

1

425-15-31151

HOUSING

SN: H60051-UP

1шт.

2

569-15-41310

SLEEVE

SN: H60051-(100030)

15шт.

3

425-15-32751

PISTON

SN: H60051-UP

2шт.

4

113-15-12870

RING

SN: H60051-UP

2шт.

5

144-15-22881

RING, SEAL

SN: H60051-UP

2шт.

6

421-15-11270

PIN

SN: H60051-UP

5шт.

7

145-14-12760

PIN

SN: H60051-UP

5шт.

8

155-15-12770

PIN

SN: H60051-UP

5шт.

9

425-15-32910

SPRING

SN: H60051-UP

10шт.

10

421-15-12910

SPRING

SN: H60051-UP

20шт.

11

425-15-32921

SPRING

SN: H60051-UP

10шт.
