Запчасти Komatsu WA500-6 U-A МАРКИРОВКА АНГЛ. МАРКИРОВКА

|$0

421-93-21311

DECAL KIT

SN: A93001--UP

1шт.

1

NSS

DECAL, CAUTION - KEEP OUT

SN: A93001--UP

1шт.

2

NSS

DECAL, CENTER PIN LOCK - SAFETY BAR

SN: A93001--UP

1шт.

3

NSS

DECAL, SAFETY - RADIATOR CAP

SN: A93001--UP

1шт.

4

NSS

DECAL, SAFETY - HYDRAULIC TANK CAP

SN: A93001--UP

1шт.

5

NSS

DECAL, CAUTION - BATTERY CABLE

SN: A93001--UP

1шт.

6

425-93-41154

DECAL, LUBRICATION CHART

SN: A93001-A93028-UP

1шт.

6

425-93-41155

DECAL, LUBRICATION CHART

SN: A93029--UP

1шт.

7

425-93-41112

DECAL, WA500 - L.H.

SN: A93001--UP

1шт.

8

425-93-41120

DECAL, WA500 - R.H.

SN: A93001--UP

1шт.

9

425-93-41130

DECAL, WA500 - R.H.

SN: A93001--UP

1шт.

10

425-93-41140

DECAL, MARK - LINE

SN: A93001--UP

2шт.

11

09690-P0900

DECAL, MARK - KOMATSU LOGO

SN: A93001--UP

2шт.

12

427-93-11310

DECAL, CHECK OIL LEVEL

SN: A93001--UP

1шт.

13

09637-30163

DECAL, INSTRUCTION - AIR CLEANER

SN: A93001--UP

1шт.

|$15

425-93-41162

DECAL KIT

SN: A93001--UP

1шт.

14

NSS

DECAL, GREASING POINT

SN: A93001--UP

1шт.

15

NSS

DECAL, GREASING POINT

SN: A93001--UP

1шт.

16

NSS

DECAL, GREASING POINT

SN: A93001--UP

1шт.

17

NSS

DECAL, RADIATOR DRAIN INSIDE

SN: A93001--UP

1шт.

18

NSS

DECAL, RADIATOR DRAIN

SN: A93001--UP

1шт.

19

NSS

DECAL, ENGINE OIL DRAIN

SN: A93001--UP

1шт.

20

NSS

DECAL, FUEL TANK DRAIN

SN: A93001--UP

1шт.

21

09669-0000E

DECAL, CAUTION - FUEL FILLER

SN: A93001--UP

1шт.

22

09812-03000

DECAL, SAFETY - KEEP OFF

SN: A93001--UP

2шт.

23

09807-C1201

DECAL, SAFETY - WORK EQUIPMENT

SN: A93001--UP

2шт.

24

09960-01601

DECAL, MARK - LIFT POINT

SN: A93001--UP

4шт.

25

NSS

PLATE, NAME

SN: A93001--UP

1шт.

26

04418-13060

SCREW

SN: A93001--UP

4шт.

27

09659-53000

DECAL, SAFETY - EXPLOSION HAZARD

SN: A93001--UP

4шт.

28

09669-0000A

DECAL, CAUTION - WATER FILLER

SN: A93001--UP

1шт.

29

6217-71-6470

DECAL, REPLACE FUEL FILTER

SN: A93001--UP

1шт.

30

09805-03000

DECAL, SAFETY - FENDER

SN: A93001--UP

2шт.

31

426-93-43340

DECAL, FAN NET

SN: A93001--UP

1шт.

32

20Y-00-41530

DECAL, ECOT 3

SN: A93001--UP

1шт.

33

09805-13000

DECAL, SAFETY - HOOD

SN: A93001--UP

1шт.

34

09667-03001

DECAL, SAFETY - ROTATING OBJECT

SN: A93001--UP

2шт.

35

09664-30011

DECAL, DANGER - BATTERY

SN: A93001--UP

2шт.

36

09690-P0500

DECAL, KOMATSU (DOORS)

SN: A93001--UP

2шт.

37

425-93-A1100

DECAL, KOMATSU (WINDSHIELD)

SN: A93001--UP

1шт.

N/I

09845-00480

DECAL, KOMTRAX BLAST ZONE WARNING

1шт.
