Запчасти Komatsu WA500-6 A-AA ТОПЛИВН. НАСОС (/) ДВИГАТЕЛЬ

|$26

FUEL SUPPLY PUMP (SEE FIG. A4020-A4A0)

0

-1шт.

|$1

ND094200-0400

FEED PUMP ASSEMBLY

1шт.

1

ND094210-0090

HOUSING ASSEMBLY

1шт.

2

ND094231-0060

CASING

1шт.

3

ND094230-0080

PUMP ASSEMBLY, SUB

1шт.

4

ND094241-0040

PLATE

1шт.

5

ND094244-0040

PLATE

1шт.

6

ND094251-0050

COVER

1шт.

7

ND094082-0040

SCREW

4шт.

8

ND094086-0200

O-RING

1шт.

9

ND094087-0050

SEAL, OIL

1шт.

10

ND094205-0060

KEY

1шт.

11

ND092124-0010

SPRING, CHECK VALVE

2шт.

12

ND092121-0011

VALVE, CHECK

2шт.

13

ND092126-0010

PLUG, CHAMBER

1шт.

14

ND092130-0360

PUMP, PRIMING

1шт.

15

ND092125-0010

GASKET

2шт.

16

ND090317-0060

PLUG, SCREW

2шт.

17

ND949018-1500

WASHER, 1.00 MM

2шт.

18

ND949044-3320

BOLT

4шт.

19

ND090222-0070

WASHER

6шт.

20

ND090310-0490

VALVE, OVERFLOW

1шт.

21

ND092220-0040

FILTER

1шт.

22

ND092223-0042

SCREW

1шт.

23

ND494044-3320

BOLT

1шт.

24

ND096449-0070

BOLT, SOCKET

4шт.

|$27

26

-1шт.

|$28

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

27

-1шт.
