Запчасти Komatsu WA500-6 H-9A ГИДР. НАСОС. GROUND ПРИВОДN РУЛЕВ. УПРАВЛЕНИЕ ГИДРАВЛИКА

|$0

704-30-34120

PUMP ASSEMBLY (SAM2) (SAM2-50)

SN: A93001--UP

-1шт.

1

704-37-02030

BRACKET

SN: A93001--UP

1шт.

2

704-37-02350

BEARING

SN: A93001--UP

2шт.

3

704-37-02180

COVER

SN: A93001--UP

1шт.

4

704-37-02350

BEARING

SN: A93001--UP

2шт.

5

704-37-02610

PLATE, SIDE

SN: A93001--UP

2шт.

6

704-37-02440

RING, SEAL

SN: A93001--UP

4шт.

7

704-37-02450

RING, BACK-UP

SN: A93001--UP

4шт.

8

704-37-02470

RING, BACK-UP

SN: A93001--UP

4шт.

9

07000-12100

O-RING

SN: A93001--UP

2шт.

10

705-17-02810

SEAL, OIL

SN: A93001--UP

1шт.

11

04065-04018

RING, SNAP

SN: A93001--UP

1шт.

12

704-37-34010

CASE, GEAR

SN: A93001--UP

1шт.

13

705-17-34410

GEAR, DRIVE

SN: A93001--UP

1шт.

14

705-17-34511

GEAR, DRIVEN

SN: A93001--UP

1шт.

15

01253-61400

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

16

705-17-04980

WASHER, LOCK

SN: A93001--UP

4шт.

17

04020-01024

PIN, DOWEL

4шт.

|$18

18

-1шт.

|$19

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

19

-1шт.
