Запчасти Komatsu WA500-6 H-8A ГИДР. НАСОС. ОХЛАЖД-Е (ДЛЯ ТОРМОЗ. СИСТЕМА ОХЛАЖДЕНИЯ) (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-08A0)

SN: A93001--UP

-1шт.

|$1

705-13-23650

PUMP ASSEMBLY (SAL(2)14)

SN: A93001--UP

1шт.

1

705-19-02570

BRACKET ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-02353

BUSHING, PLANE

SN: A93001--UP

2шт.

2

04020-01228

PIN, DOWEL

SN: A93001--UP

2шт.

3

705-17-02122

COVER ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-02353

BUSHING, PLANE

SN: A93001--UP

2шт.

4

705-17-02612

PLATE, SIDE

SN: A93001--UP

2шт.

5

705-17-02430

RING, BACKUP

SN: A93001--UP

2шт.

6

705-17-02460

RING, SEAL

SN: A93001--UP

2шт.

7

705-17-02360

O-RING

SN: A93001--UP

2шт.

8

705-17-02870

PLATE

SN: A93001--UP

1шт.

9

705-17-02950

SEAL, OIL

SN: A93001--UP

1шт.

10

705-18-23010

CASE, GEAR

SN: A93001--UP

1шт.

11

705-18-23450

GEAR, DRIVE

SN: A93001--UP

1шт.

12

705-18-23510

GEAR, DRIVEN

SN: A93001--UP

1шт.

13

04020-01024

PIN, DOWEL

SN: A93001--UP

4шт.

14

01252-61275

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

15

01643-51232

WASHER

SN: A93001--UP

4шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
