Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР И PPC (ДЛЯ ТОРМОЗ. СИСТЕМА ОХЛАЖДЕНИЯ) (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-04A0)

SN: A93001--UP

-1шт.

|$1

705-12-23640

PUMP ASSEMBLY (SAR14)

SN: A93001--UP

1шт.

1

705-17-01540

BRACKET ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING

SN: A93001--UP

2шт.

2

04020-00820

PIN, DOWEL

SN: A93001--UP

2шт.

3

705-17-01121

COVER ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING

SN: A93001--UP

2шт.

4

705-17-01610

PLATE, SIDE

SN: A93001--UP

2шт.

5

705-67-01440

RING, BACKUP

SN: A93001--UP

2шт.

6

705-67-01470

SEAL, RING

SN: A93001--UP

2шт.

7

705-67-01380

O-RING

SN: A93001--UP

2шт.

8

705-17-01860

PLATE

SN: A93001--UP

1шт.

9

705-17-01950

SEAL, OIL

SN: A93001--UP

1шт.

10

705-17-23010

CASE, GEAR

SN: A93001--UP

1шт.

11

705-17-23450

GEAR, DRIVE

SN: A93001--UP

1шт.

12

705-17-23510

GEAR, DRIVEN

SN: A93001--UP

1шт.

13

04020-00820

PIN, DOWEL

SN: A93001--UP

4шт.

14

01252-61280

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

15

01643-51232

WASHER

SN: A93001--UP

4шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
