Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР И PPC (ДЛЯ ТОРМОЗ. СИСТЕМА ОХЛАЖДЕНИЯ) (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-04A0)

SN: A93001--UP

-1шт.

|$1

705-34-29440

PUMP ASSEMBLY (SAR28)

SN: A93001--UP

1шт.

1

705-19-01541

BRACKET ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING, PLANE

SN: A93001--UP

2шт.

2

04020-01228

PIN, DOWEL

SN: A93001--UP

2шт.

3

705-17-01221

CARRIER ASSEMBLY

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING, PLANE

SN: A93001--UP

2шт.

4

705-17-01610

PLATE, SIDE

SN: A93001--UP

2шт.

5

705-67-01440

RING, BACK-UP

SN: A93001--UP

2шт.

6

705-67-01470

SEAL, RING

SN: A93001--UP

2шт.

7

705-67-01380

O-RING

SN: A93001--UP

2шт.

8

705-17-01860

PLATE

SN: A93001--UP

1шт.

9

705-17-01950

SEAL, OIL

SN: A93001--UP

1шт.

10

04065-03212

RING, SNAP

SN: A93001--UP

1шт.

11

705-18-29110

CASE, GEAR

SN: A93001--UP

1шт.

12

705-18-29760

GEAR, DRIVE

SN: A93001--UP

1шт.

13

705-18-29810

GEAR, DRIVEN

SN: A93001--UP

1шт.

14

04020-00820

PIN, DOWEL

SN: A93001--UP

4шт.

15

01253-61205

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

16

01643-51232

WASHER

SN: A93001--UP

4шт.

|$20

20

-1шт.

|$21

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

21

-1шт.
