Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР И PPC (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-03A0)

SN: A93001--UP

-1шт.

|$1

705-34-29640

PUMP ASSEMBLY (SAR28)

SN: A93001--UP

1шт.

1

705-19-01541

BRACKET

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING, PLANE

SN: A93001--UP

2шт.

2

705-18-29110

CASE, GEAR

SN: A93001--UP

1шт.

3

705-17-01121

COVER

SN: A93001--UP

1шт.

N/I

705-17-01351

BUSHING, PLANE

SN: A93001--UP

2шт.

4

705-18-29750

GEAR, DRIVE

SN: A93001--UP

1шт.

5

705-18-29810

GEAR, DRIVEN

SN: A93001--UP

1шт.

6

705-17-01610

PLATE, SIDE

SN: A93001--UP

2шт.

7

705-67-01470

SEAL, RING

SN: A93001--UP

2шт.

8

705-67-01440

RING, BACK-UP

SN: A93001--UP

2шт.

9

705-67-01380

O-RING

SN: A93001--UP

2шт.

10

04020-00820

PIN, DOWEL

SN: A93001--UP

4шт.

11

01252-61295

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

12

01643-51232

WASHER

SN: A93001--UP

4шт.

13

04020-01228

PIN, DOWEL

SN: A93001--UP

2шт.

14

705-17-01950

SEAL, OIL

SN: A93001--UP

1шт.

15

04065-03212

RING, SNAP

SN: A93001--UP

1шт.

16

705-17-01860

PLATE

SN: A93001--UP

1шт.

17

705-19-01330

COUPLING

SN: A93001--UP

1шт.

18

705-17-03381

O-RING

SN: A93001--UP

1шт.

19

01252-61445

BOLT, SOCKET HEAD

SN: A93001--UP

4шт.

20

705-17-04980

WASHER

SN: A93001--UP

4шт.

|$24

24

-1шт.

|$25

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

25

-1шт.
