Запчасти Komatsu WA500-6 H-A7 ГИДР. НАСОС. ПОГРУЗ. НАСОС ASSEMBLY (ГЛАВН. И РАСПРЕДЕЛИТ. КЛАПАН) (8/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-02A0)

SN: A93001--UP

-1шт.

1

702-21-57400

VALVE, PILOT

SN: A93001--UP

1шт.

2

01252-60635

BOLT, SOCKET HEAD

SN: A93001--UP

2шт.

3

708-2G-15680

PLUG

SN: A93001--UP

1шт.

4

07000-B1008

O-RING

SN: A93001--UP

1шт.

5

07001-01008

RING, BACK-UP

SN: A93001--UP

2шт.

6

07002-61423

O-RING

SN: A93001--UP

1шт.

7

01643-51232

WASHER

SN: A93001--UP

1шт.

8

01010-81220

BOLT

SN: A93001--UP

1шт.

9

08193-21012

CLIP

SN: A93001--UP

1шт.

|$10

720-2M-03551

VALVE ASSEMBLY, SHUTTLE

SN: A93001--UP

1шт.

10

07002-61423

O-RING

SN: A93001--UP

1шт.

11

720-2M-15412

SLEEVE

SN: A93001--UP

1шт.

12

720-2M-15421

HOLDER

SN: A93001--UP

1шт.

13

720-2M-15430

SEAL

SN: A93001--UP

1шт.

14

700-84-11730

BALL

SN: A93001--UP

1шт.

15

720-2M-15440

SEAL

SN: A93001--UP

1шт.

|$17

17

-1шт.

|$18

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

18

-1шт.
