Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС ASSEMBLY (IMPELLER) (/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-02A0)

SN: A93001--UP

-1шт.

|$1

PUMP ASSEMBLY (SEE FIG. H0210-02A0)

SN: A93001--UP

1шт.

1

708-1H-21630

IMPELLER

SN: A93001--UP

1шт.

2

708-1E-05010

WASHER KIT

SN: A93001--UP

1шт.

|$4

NSS

WASHER, T=2.7 MM

SN: A93001--UP

1шт.

|$5

NSS

WASHER, T=3.0 MM

SN: A93001--UP

1шт.

|$6

NSS

WASHER, T=3.3 MM

SN: A93001--UP

1шт.

|$7

NSS

WASHER, T=3.6 MM

SN: A93001--UP

1шт.

3

04010-00522

KEY

SN: A93001--UP

1шт.

4

708-1E-11640

WASHER

SN: A93001--UP

1шт.

5

01583-12414

NUT

SN: A93001--UP

1шт.

6

708-1H-21622

COVER

SN: A93001--UP

1шт.

7

708-1H-32530

O-RING

SN: A93001--UP

1шт.

8

01010-81230

BOLT

SN: A93001--UP

6шт.

9

01643-31232

WASHER

SN: A93001--UP

6шт.

|$15

15

-1шт.

|$16

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

16

-1шт.
