Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС ASSEMBLY (ВАЛ И ПОРШЕНЬ) (/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-02A0)

SN: A93001--UP

-1шт.

|$1

PUMP ASSEMBLY (SEE FIG. H0210-02A0)

SN: A93001--UP

1шт.

1

708-1H-32130

SHAFT

SN: A93001--UP

1шт.

2

708-17-05010

WASHER KIT

SN: A93001--UP

1шт.

|$4

NSS

WASHER, T=3.0 MM

SN: A93001--UP

1шт.

|$5

NSS

WASHER, T=3.1 MM

SN: A93001--UP

1шт.

|$6

NSS

WASHER, T=3.2 MM

SN: A93001--UP

1шт.

3

708-17-12780

RING, SNAP

SN: A93001--UP

1шт.

4

708-1H-22150

BEARING

SN: A93001--UP

1шт.

5

708-2H-22570

SEAL, OIL

SN: A93001--UP

1шт.

6

708-2H-22160

SPACER

SN: A93001--UP

1шт.

7

04065-08225

RING, SNAP

SN: A93001--UP

1шт.

|$12

708-2H-04750

CYLINDER BLOCK ASSEMBLY

SN: A93001--UP

1шт.

8

708-2H-33180

BLOCK, CYLINDER

SN: A93001--UP

1шт.

9

708-2H-33421

PLATE, VALVE

SN: A93001--UP

1шт.

10

708-18-13230

PIN, DOWEL

SN: A93001--UP

1шт.

11

04065-05820

RING, SNAP

SN: A93001--UP

1шт.

12

708-2H-33140

SEAT

SN: A93001--UP

1шт.

13

708-2H-33150

SPRING

SN: A93001--UP

1шт.

14

708-2H-23141

SEAT

SN: A93001--UP

1шт.

15

708-2H-23350

GUIDE

SN: A93001--UP

1шт.

16

708-2H-23360

PIN, DOWEL

SN: A93001--UP

3шт.

17

708-2H-33343

RETAINER

SN: A93001--UP

1шт.

18

708-2H-33311

PISTON

SN: A93001--UP

9шт.

|$24

708-2H-04690

CRADLE ASSEMBLY

SN: A93001--UP

1шт.

19

708-2H-33511

CRADLE

SN: A93001--UP

1шт.

20

708-2H-33440

CAM

SN: A93001--UP

1шт.

21

04020-01434

PIN, DOWEL

SN: A93001--UP

1шт.

22

07000-B1009

O-RING

SN: A93001--UP

1шт.

23

01252-61235

BOLT, SOCKET HEAD

SN: A93001--UP

6шт.

|$30

30

-1шт.

|$31

F1 - THIS PARTS IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

31

-1шт.
