Запчасти Komatsu WA500-6 M-9A ВЕНТИЛЯТОР ОХЛАЖДЕНИЯ МОТОР (/) ЧАСТИ КОРПУСА

|$0

MOTOR ASSEMBLY (SEE FIG. M4110-28A0 )

SN: A92001--UP

-1шт.

1

07000-E2110

O-RING

SN: A92001--UP

1шт.

2

04020-00616

PIN, DOWEL

SN: A92001--UP

2шт.

3

01252-61255

BOLT

SN: A92001--UP

4шт.

4

708-7S-12330

SHAFT

SN: A92001--UP

1шт.

5

708-7T-12520

BEARING

SN: A92001--UP

1шт.

6

708-7T-12530

BEARING

SN: A92001--UP

1шт.

7

708-7S-05110

SHIM KIT

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 0.85 MM

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 1.05 MM

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 1.25 MM

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 0.75 MM

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 0.95 MM

SN: A92001--UP

1шт.

N/I

NSS

SHIM, 1.15 MM

SN: A92001--UP

1шт.

8

708-7T-12330

SEAL, OIL

SN: A92001--UP

1шт.

9

708-1S-11890

SPACER

SN: A92001--UP

1шт.

10

04065-04518

RING, SNAP

SN: A92001--UP

1шт.

11

708-7T-13810

BLOCK, CYLINDER

SN: A92001--UP

1шт.

12

708-7T-13830

PLATE, VALVE

SN: A92001--UP

1шт.

13

720-68-19610

PIN

SN: A92001--UP

1шт.

14

708-2L-23360

PIN

SN: A92001--UP

3шт.

15

708-7S-13530

SPACER

SN: A92001--UP

2шт.

16

708-7T-13840

SPRING

SN: A92001--UP

1шт.

17

04065-03212

RING, SNAP

SN: A92001--UP

1шт.

18

708-7T-13820

GUIDE, RETAINER

SN: A92001--UP

1шт.

19

708-7T-13850

RETAINER, SHOE

SN: A92001--UP

1шт.

20

708-7S-13350

PISTON SUBASSEMBLY

SN: A92001--UP

7шт.

21

708-7T-13860

PLATE, THRUST

SN: A92001--UP

1шт.

|$28

28

-1шт.

|$29

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS SUPPLIED AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

29

-1шт.
