Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. РУЛЕВ. УПРАВЛЕНИЕ (КЛАПАН ASSEMBLY) (/) ГИДРАВЛИКА

|$0

STEERING PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$1

708-1W-03830

VALVE ASSEMBLY

SN: A92001--UP

1шт.

|$2

NSS

BODY ASSEMBLY

SN: A92001--UP

1шт.

1

NSS

BODY

SN: A92001--UP

1шт.

2

NSS

PLUG

SN: A92001--UP

11шт.

|$5

708-1W-03850

SLEEVE ASSEMBLY

SN: A92001--UP

1шт.

3

NSS

SLEEVE

SN: A92001--UP

1шт.

4

NSS

PISTON

SN: A92001--UP

1шт.

5

NSS

PISTON

SN: A92001--UP

1шт.

6

708-3S-15790

SEAL

SN: A92001--UP

1шт.

7

07002-11623

O-RING

SN: A92001--UP

1шт.

8

708-1S-15470

SPOOL

SN: A92001--UP

1шт.

9

708-1W-45391

SEAT

SN: A92001--UP

1шт.

10

NSS

SPRING

SN: A92001--UP

1шт.

11

07002-11423

O-RING

SN: A92001--UP

1шт.

12

NSS

PLUG

SN: A92001--UP

1шт.

13

NSS

PLUG

SN: A92001--UP

1шт.

|$17

708-1U-03510

SPOOL SUBASSEMBLY

SN: A92001--UP

1шт.

14

708-1U-15610

SPOOL

SN: A92001--UP

1шт.

15

708-1T-15560

PLUG

SN: A92001--UP

1шт.

16

708-1T-15570

SPRING

SN: A92001--UP

1шт.

17

708-1T-15580

BALL

SN: A92001--UP

1шт.

18

NSS

PLUG

SN: A92001--UP

1шт.

19

07002-11223

O-RING

SN: A92001--UP

2шт.

20

NSS

SPRING

SN: A92001--UP

1шт.

21

708-1U-15630

SEAT

SN: A92001--UP

1шт.

22

708-1S-15930

ORIFICE

SN: A92001--UP

1шт.

|$27

27

-1шт.

|$28

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

28

-1шт.
