Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. РУЛЕВ. УПРАВЛЕНИЕ (/) ГИДРАВЛИКА

|$0

STEERING PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$40

OR

1

-1шт.

|$2

STEERING PUMP ASSEMBLY (FOR BRAKE COOL ING SYSTEM) (SEE FIG. H0210-01A1 )

SN: A92001--UP

-1шт.

|$3

708-1W-01953

PUMP SUBASSEMBLY

SN: A92001--UP

1шт.

|$4

708-1W-04941

CASE ASSEMBLY

SN: A92001--UP

1шт.

1

708-1W-41241

CASE, PUMP

SN: A92001--UP

1шт.

2

NSS

PLUG

SN: A92001--UP

5шт.

3

708-1W-44311

SLEEVE

SN: A92001--UP

1шт.

4

708-1W-44220

RING

SN: A92001--UP

1шт.

5

708-8E-16160

PLUG

SN: A92001--UP

1шт.

6

07002-11023

O-RING

SN: A92001--UP

1шт.

7

07040-11409

PLUG

SN: A92001--UP

1шт.

8

07002-11423

O-RING

SN: A92001--UP

1шт.

9

706-73-42370

O-RING

SN: A92001--UP

1шт.

10

07000-B1009

O-RING

SN: A92001--UP

1шт.

11

04020-01024

PIN, DOWEL

SN: A92001--UP

1шт.

12

01010-61470

BOLT

SN: A92001--UP

4шт.

13

01643-31445

WASHER

SN: A92001--UP

4шт.

|$18

708-1W-03930

PLUG ASSEMBLY

SN: A92001--UP

1шт.

14

708-1W-45490

PLUG

SN: A92001--UP

1шт.

15

720-2M-15430

SEAL

SN: A92001--UP

1шт.

16

720-2M-15440

SEAL

SN: A92001--UP

1шт.

17

NSS

CAP, END

SN: A92001--UP

1шт.

18

708-1W-42120

BEARING

SN: A92001--UP

1шт.

19

708-3T-13421

BALL

SN: A92001--UP

2шт.

20

708-1W-43610

CAM, ROCKER

SN: A92001--UP

1шт.

21

708-1U-12120

SHAFT

SN: A92001--UP

1шт.

22

708-1W-42110

BEARING

SN: A92001--UP

1шт.

23

708-1W-42140

CASE, SEAL

SN: A92001--UP

1шт.

24

708-1W-42130

SEAL, OIL

SN: A92001--UP

1шт.

25

07000-B2060

O-RING

SN: A92001--UP

1шт.

26

708-1W-05820

SPACER KIT

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.3 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.4 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.5 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.6 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER. 2.7 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.8 MM

SN: A92001--UP

1шт.

N/I

NSS

SPACER, 2.9 MM

SN: A92001--UP

1шт.

27

04065-06825

RING, SNAP

SN: A92001--UP

1шт.

|$41

40

-1шт.

|$42

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

41

-1шт.
