Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ОХЛАЖД-Е (ДЛЯ ТОРМОЗ. СИСТЕМА ОХЛАЖДЕНИЯ) (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SAL(3)80)+(SAL(2)14) (SEE FIG. H0210-01A1 )

SN: A92001--UP

-1шт.

|$1

705-37-38010

PUMP ASSEMBLY (SAL(3)80)

SN: A92001--UP

1шт.

1

705-18-03770

BRACKET ASSEMBLY

SN: A92001--UP

1шт.

N/I

705-17-03352

BUSHING

SN: A92001--UP

2шт.

2

705-17-38010

CASE, GEAR

SN: A92001--UP

1шт.

3

705-17-03220

CARRIER ASSEMBLY

SN: A92001--UP

1шт.

N/I

705-17-03352

BUSHING

SN: A92001--UP

2шт.

4

705-29-38130

GEAR, DRIVE

SN: A92001--UP

1шт.

5

705-17-38511

GEAR, DRIVEN

SN: A92001--UP

1шт.

6

705-17-03610

PLATE, SIDE

SN: A92001--UP

2шт.

7

705-17-03443

RING

SN: A92001--UP

2шт.

8

705-17-03473

SEAL

SN: A92001--UP

2шт.

9

705-17-03381

O-RING

SN: A92001--UP

2шт.

10

04020-01228

PIN, DOWEL

SN: A92001--UP

4шт.

11

01253-61625

BOLT

SN: A92001--UP

4шт.

12

01643-51645

WASHER

SN: A92001--UP

4шт.

13

705-17-03870

PLATE

SN: A92001--UP

1шт.

14

705-17-03811

SEAL, OIL

SN: A92001--UP

1шт.

15

04065-05220

RING, SNAP

SN: A92001--UP

1шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
