Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ЭКСТРЕНН. РУЛЕВ. УПРАВЛЕНИЕ ГИДРАВЛИКА

|$0

704-30-34120

PUMP ASSEMBLY (SAM2)

SN: A92001--UP

-1шт.

1

704-37-02030

BRACKET

SN: A92001--UP

1шт.

2

704-37-34010

CASE, GEAR

SN: A92001--UP

1шт.

3

704-37-02180

COVER

SN: A92001--UP

1шт.

4

705-17-34410

GEAR, DRIVE

SN: A92001--UP

1шт.

5

705-17-34511

GEAR, DRIVEN

SN: A92001--UP

1шт.

6

704-37-02350

BEARING

SN: A92001--UP

4шт.

7

704-37-02610

PLATE, SIDE

SN: A92001--UP

2шт.

8

704-37-02440

RING, SEAL

SN: A92001--UP

4шт.

9

704-37-02470

RING, BACK-UP

SN: A92001--UP

4шт.

10

704-37-02450

RING, BACK-UP

SN: A92001--UP

4шт.

11

07000-12100

O-RING

SN: A92001--UP

2шт.

12

04020-01024

PIN, DOWEL

SN: A92001--UP

4шт.

13

01253-61400

BOLT

SN: A92001--UP

4шт.

14

01602-01442

WASHER, LOCK

SN: A92001--UP

4шт.

15

705-17-02830

SEAL, OIL

SN: A92001--UP

1шт.

16

04065-04018

RING, SNAP

SN: A92001--UP

1шт.

|$17

17

-1шт.

|$18

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

18

-1шт.
