Запчасти Komatsu WA500-6 H-9A ГИДР. НАСОС. ВЕНТИЛЯТОР (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$1

NSS

PUMP SUBASSEMBLY

SN: A92001--UP

1шт.

|$2

708-1T-04610

CASE SUBASSEMBLY

SN: A92001--UP

1шт.

1

NSS

CASE, PUMP

SN: A92001--UP

1шт.

2

NSS

PLUG

SN: A92001--UP

1шт.

3

NSS

PLUG

SN: A92001--UP

3шт.

4

708-1T-13580

CAM, ROCKER

SN: A92001--UP

1шт.

5

04260-01270

BALL, STEEL

SN: A92001--UP

1шт.

6

708-1T-14610

SPACER

SN: A92001--UP

1шт.

7

NSS

PIN

SN: A92001--UP

2шт.

8

01252-60616

BOLT

SN: A92001--UP

1шт.

9

708-1S-13430

BALL

SN: A92001--UP

2шт.

10

01252-61240

BOLT

SN: A92001--UP

4шт.

11

04020-01024

PIN, DOWEL

SN: A92001--UP

2шт.

12

708-2L-25490

O-RING

SN: A92001--UP

2шт.

13

708-2L-25480

FILTER

SN: A92001--UP

2шт.

14

708-1S-19710

ORIFICE

SN: A92001--UP

2шт.

15

NSS

PLATE

SN: A92001--UP

1шт.

16

07000-E2065

O-RING

SN: A92001--UP

1шт.

17

01010-81025

BOLT

SN: A92001--UP

4шт.

18

01643-31032

WASHER

SN: A92001--UP

4шт.

|$21

708-1T-04620

CAP SUBASSEMBLY

SN: A92001--UP

1шт.

19

NSS

CAP, END

SN: A92001--UP

1шт.

20

NSS

PLUG

SN: A92001--UP

1шт.

21

720-68-19610

PIN

SN: A92001--UP

1шт.

22

07000-F1006

O-RING

SN: A92001--UP

2шт.

23

07000-E2125

O-RING

SN: A92001--UP

1шт.

24

702-21-55620

PLUG

SN: A92001--UP

1шт.

25

07040-11409

PLUG

SN: A92001--UP

1шт.

26

07002-21423

O-RING

SN: A92001--UP

2шт.

|$30

30

-1шт.

|$31

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

31

-1шт.
