Запчасти Komatsu WA500-6 H-7A ГИДР. НАСОС. ПОГРУЗ. (LS КЛАПАН) (7/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H4200-21A0 )

SN: A92001--UP

-1шт.

|$1

708-1H-03310

VALVE ASSEMBLY, LS

SN: A92001--UP

1шт.

1

708-2L-35311

SLEEVE

SN: A92001--UP

1шт.

2

708-2L-24680

SEAL

SN: A92001--UP

4шт.

3

708-2G-15412

SPOOL

SN: A92001--UP

1шт.

4

NSS

PISTON

SN: A92001--UP

1шт.

5

708-2L-35360

SLEEVE

SN: A92001--UP

1шт.

6

708-2G-15440

SEAT

SN: A92001--UP

1шт.

7

708-2L-35410

SPRING

SN: A92001--UP

1шт.

8

708-2L-35341

SEAT

SN: A92001--UP

1шт.

9

708-2L-35351

PLUG

SN: A92001--UP

1шт.

10

07000-B1009

O-RING

SN: A92001--UP

1шт.

11

07001-01009

RING, BACK-UP

SN: A92001--UP

1шт.

12

01583-11408

NUT

SN: A92001--UP

1шт.

13

07002-62434

O-RING

SN: A92001--UP

1шт.

|$15

15

-1шт.

|$16

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

16

-1шт.
