Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ПОГРУЗ. (COVER) (/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H4200-21A0 )

SN: A92001--UP

-1шт.

|$2

708-1H-03250

COVER ASSEMBLY

SN: A92001--UP

1шт.

1

708-2G-14310

SCREW

SN: A92001--UP

1шт.

2

07000-B3038

O-RING

SN: A92001--UP

1шт.

3

708-2G-15230

RING, BACK-UP

SN: A92001--UP

1шт.

4

708-2L-35290

NUT

SN: A92001--UP

1шт.

5

708-2L-44130

COVER

SN: A92001--UP

1шт.

6

07000-B2050

O-RING

SN: A92001--UP

1шт.

7

708-2G-15310

RING

SN: A92001--UP

1шт.

8

01252-61645

BOLT

SN: A92001--UP

4шт.

|$11

11

-1шт.

|$12

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

12

-1шт.
