Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ПОГРУЗ. (PC КЛАПАН) (/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H4200-21A0 )

SN: A92001--UP

-1шт.

1

708-2H-34150

SLIDER

SN: A92001--UP

1шт.

|$3

708-1H-03230

VALVE ASSEMBLY, PC

SN: A92001--UP

1шт.

|$4

708-1H-03240

PISTON ASSEMBLY, SERVO

SN: A92001--UP

1шт.

2

NSS

PISTON, SERVO

SN: A92001--UP

1шт.

3

NSS

SCREW

SN: A92001--UP

8шт.

4

708-2G-15320

SEAL

SN: A92001--UP

1шт.

5

708-2H-15310

PLUG

SN: A92001--UP

1шт.

6

708-2L-35760

BALL

SN: A92001--UP

1шт.

7

708-2L-35770

PLUG

SN: A92001--UP

1шт.

8

708-2L-35690

SEAL

SN: A92001--UP

3шт.

9

708-2L-35170

PIN

SN: A92001--UP

1шт.

10

708-2G-15211

SPOOL

SN: A92001--UP

1шт.

11

708-2G-15290

RETAINER

SN: A92001--UP

1шт.

12

708-2G-15140

SEAT

SN: A92001--UP

1шт.

13

708-1H-34220

SPRING

SN: A92001--UP

1шт.

14

708-1H-34230

SPRING

SN: A92001--UP

1шт.

15

708-2G-14340

SCREW

SN: A92001--UP

1шт.

16

07000-B3038

O-RING

SN: A92001--UP

1шт.

17

708-2G-15230

RING, BACK-UP

SN: A92001--UP

1шт.

18

708-2G-15260

SEAL

SN: A92001--UP

1шт.

19

708-2G-15390

PLUG

SN: A92001--UP

1шт.

20

07000-B2012

O-RING

SN: A92001--UP

1шт.

21

07000-B2050

O-RING

SN: A92001--UP

1шт.

22

708-2G-15310

RING

SN: A92001--UP

1шт.

23

708-2L-44161

COVER

SN: A92001--UP

1шт.

24

01580-10806

NUT

SN: A92001--UP

1шт.

25

708-2L-35290

NUT

SN: A92001--UP

1шт.

26

708-2G-15330

RING

SN: A92001--UP

1шт.

27

01252-61645

BOLT

SN: A92001--UP

4шт.

|$31

31

-1шт.

|$32

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

32

-1шт.
