Запчасти Komatsu WA500-6 H-A ГИДР. НАСОС. ПОГРУЗ. (ПЕРЕДН. КОРПУС) (/8) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

SN: A92001--UP

-1шт.

|$1

708-1H-01030

PUMP SUBASSEMBLY

SN: A92001--UP

1шт.

|$2

708-1H-04510

CASE ASSEMBLY, FRONT

SN: A92001--UP

1шт.

1

NSS

CASE, FRONT

SN: A92001--UP

1шт.

2

NSS

PLUG

SN: A92001--UP

32шт.

3

07044-12412

PLUG

SN: A92001--UP

1шт.

4

07002-62434

O-RING

SN: A92001--UP

1шт.

5

708-2H-21740

PLUG

SN: A92001--UP

1шт.

6

07002-62434

O-RING

SN: A92001--UP

1шт.

7

04530-11222

BOLT, EYE

SN: A92001--UP

2шт.

8

708-1L-29340

ORIFICE

SN: A92001--UP

1шт.

9

708-8E-16150

PLUG

SN: A92001--UP

3шт.

10

07002-61023

O-RING

SN: A92001--UP

3шт.

|$13

13

-1шт.

|$14

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

14

-1шт.
