Запчасти Komatsu WA500-6 F-A ГТР СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

425-13-30011

TORQUEFLOW ASSEMBLY

SN: A92001--UP

1шт.

1

TORQUE CONVERTER (WITH LOCK-UP) (SEE FIG. F4310-51A1 )

SN: A92001--UP

-1шт.

2

TORQUE CONVERTER (SEE FIG. F4310-51A0 )

SN: A92001--UP

-1шт.

3

425-13-33711

TUBE

SN: A92001--UP

1шт.

4

07206-31014

BOLT

SN: A92001--UP

2шт.

5

07005-01412

GASKET

SN: A92001--UP

4шт.

6

425-15-33770

TUBE

SN: A92001--UP

1шт.

7

01010-81050

BOLT

SN: A92001--UP

4шт.

8

203-54-56970

WASHER

SN: A92001--UP

4шт.

9

07000-73035

O-RING

SN: A92001--UP

2шт.

|$10

425-13-05200

SERVICE KIT, TORQUE CONVERTER

SN: A92001--UP

1шт.

|$11

425-15-05601

SERVICE KIT, TRANSMISSION

SN: A92001--UP

1шт.

|$12

425-15-05450

SERVICE KIT, TRANSMISSION CONTROL VALVE

SN: A92001--UP

1шт.

|$13

13

-1шт.

|$14

F1 - SERVICEABLE PARTS LOCATED IN SERVICE KITS.

14

-1шт.
