Запчасти Komatsu WA500-3LK СИДЕНЬЕ ОПЕРАТОРА (ВНУТР. ЧАСТИ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

426-57-21211

SEAT ASS'Y,OPERATOR'S

SN: A71001-UP

1шт.

|$1

426-57-21112

SEAT ASS'Y

SN: A71001-UP

1шт.

|$2

BS170250

UPPER ASS'Y

SN: A71001-UP

1шт.

1

0

BACK COVER KIT

SN: A71001-UP

1шт.

2

0

BACK FOAM KIT

SN: A71001-UP

1шт.

3

0

SEAT COVER KIT

SN: A71001-UP

1шт.

4

0

SEAT FOAM KIT

SN: A71001-UP

1шт.

5

0

SUPPORT KIT

SN: A71001-UP

1шт.

6

0

FRAME KIT

SN: A71001-UP

1шт.

7

BS157157

LATCH KIT

SN: A71001-UP

1шт.

8

BS160055

HEIGHT RISER KIT

SN: A71001-UP

1шт.

9

BS157117

HANDLE KIT

SN: A71001-UP

1шт.

10

BS156713

SPRING KIT

SN: A71001-UP

1шт.

11

BS174717

SUSPENSION ASS'Y

SN: A71001-UP

1шт.

12

BS174619

DAMPER ASS'Y KIT

SN: A71001-UP

1шт.

13

BS160436

STOP KIT

SN: A71001-UP

1шт.

14

BS163954

AIR SPRING KIT

SN: A71001-UP

1шт.

15

BS164191

VALVE KIT

SN: A71001-UP

1шт.

16

BS174711

COMPRESSOR KIT

SN: A71001-UP

1шт.

17

BS164000

BEARING KIT

SN: A71001-UP

1шт.

18

BS166007

LEVER KIT

SN: A71001-UP

1шт.

19

BS174719

ADJUSTER KIT

SN: A71001-UP

1шт.

20

BS174718

COVER KIT

SN: A71001-UP

1шт.

21

BS151185

HEAD REST KIT

SN: A71001-UP

1шт.

22

BS174889

ARM REST KIT

SN: A71001-UP

1шт.

23

08055-00282

CONNECTOR

SN: A71001-UP

1шт.

24

08017-30704

CONDUIT

SN: A71001-UP

1шт.
