Запчасти Komatsu WA500-3L A-AA СТАРТЕР ДВИГАТЕЛЬ
№
Артикул
Название
Примечание
Количество
|$0
1222 960 H91
MOTOR, STARTING
1шт.
1
1228 448 H91
HOUSING ASSEMBLY, DRIVE END
1шт.
2
1211 288 H1
BUSHING, DRIVE END
1шт.
3
347 360 R1
O-RING, BETWEEN HOUSINGS
1шт.
4
1211 277 H1
CUP, OIL RESERVOIR
1шт.
5
1302 333 H1
WICK, DRIVE END HOUSING
1шт.
6
NSS
HOUSING, DRIVE END
1шт.
|$7
21 241 R1
BOLT, MOUNTING
6шт.
7
1228 455 H1
PLUG, CUP (REMAINING HOUSING BOLT HOLES)
-2шт.
9
1228 447 H91
HOUSING ASSEMBLY, LEVER
1шт.
10
213 262 R1
RING, RETAINING
1шт.
11
NSS
HOUSING, LEVER
1шт.
12
1211 285 H1
SEAL, OIL
1шт.
13
1211 286 H1
WASHER, BRAKE
1шт.
14
355 967 R1
O-RING
1шт.
15
352 219 R1
O-RING
1шт.
16
1211 152 H1
SHAFT, SHIFT LEVER
1шт.
17
NSS
LEVER, SHIFT
1шт.
18
NSS
WICK, LEVER HOUSING
1шт.
19
NSS
PLUG, WICK
1шт.
20
NSS
BUSHING, LEVER HOUSING
1шт.
21
22 411 R1
O-RING, BETWEEN HOUSINGS
1шт.
22
NSS
O-RING, SOLENOID SWITCH
1шт.
23
1211 356 H1
WASHER, SPACER
1шт.
24
1211 282 H1
CABLE, SOLENOID TO END FRAME
1шт.
|$26
120 217
WASHER, LOCK - AT SOLENOID SWITCH
1шт.
|$27
115 999
NUT, HEX - AT SOLENOID SWITCH
1шт.
|$28
120 396
WASHER, FLAT - AT END FRAME
1шт.
|$29
NSS
WASHER, LOCK - AT END FRAME
1шт.
|$30
25 526 R1
NUT, HEX - AT END FRAME
1шт.
|$31
1211 267 H1
NUT AND WASHER - AT END FRAME
1шт.
25
1228 450 H1
PLUNGER, SHIFT LEVER
1шт.
26
1210 070 H1
WASHER, PLUNGER
1шт.
27
1210 071 H1
BOOT, PLUNGER
1шт.
28
1210 072 H1
RETAINER, SPRING
1шт.
29
1210 073 H1
SPRING, PLUNGER
1шт.
30
1210 074 H1
RETAINER, SPRING
1шт.
31
213 262 R1
RING, RETAINER
1шт.
32
19 839 R1
NUT, LOCK - PLUNGER
1шт.
33
1228 449 H1
SWITCH, SOLENOID
1шт.
|$41
1210 069 H1
BOLT, MOUNTING
3шт.
34
1211 271 H1
INSULATOR
1шт.
35
1211 263 H1
POLE, SHOE
4шт.
36
1211 150 H1
SCREW, POLE SHOE
8шт.
37
1228 453 H1
INSULATOR, FIELD COIL
1шт.
38
1210 061 H1
INSULATOR - INSIDE FRAME
1шт.
39
1210 062 H1
INSULATOR - OUTSIDE FRAME
1шт.
40
1228 452 H1
CONNECTOR, FIELD COIL TO SOLENOID
1шт.
|$49
1211 267 H1
NUT AND WASHER - AT SOLENOID
1шт.
|$50
NSS
BOLT, MOUNTING - AT FIELD COIL
1шт.
|$51
120 385
WASHER, FLAT - AT FIELD COIL
1шт.
41
1228 454 H1
PIN, SPRING
2шт.
42
1223 256 H1
ARMATURE
1шт.
43
1232 885 H1
WASHER, THRUST
1шт.
44
1228 605 H1
FIELD COIL
1шт.
45
NSS
PLATE, BRUSH
1шт.
|$57
1223 263 H1
SCREW AND WASHER, THRU END FRAME TO PLATE
6шт.
|$58
1211 292 H1
SCREW, FIELD COIL TO PLATE
4шт.
46
NSS
BRUSH
4шт.
47
NSS
SPRING, BRUSH
4шт.
48
1223 265 H1
LEAD, TERMINAL
1шт.
49
NSS
O-RING, BETWEEN HOUSINGS
1шт.
50
1223 269 H91
PACKAGE, TERMINAL INSULATOR
1шт.
51
1223 255 H1
HOUSING ASSEMBLY, END FRAME
1шт.
52
NSS
HOUSING, END FRAME
1шт.
53
NSS
WICK, OIL
1шт.
54
NSS
PLUG, WICK
1шт.
55
NSS
BUSHING, END FRAME
1шт.
56
1210 066 H1
PLUG, INSPECTION
1шт.
57
1211 151 H1
GASKET, PLUG
1шт.
|$71
1223 266 H91
PACKAGE, BUSHING
1шт.
2
1211 288 H1
BUSHING, DRIVE END
1шт.
3
347 360 R1
O-RING, BETWEEN HOUSINGS
1шт.
4
1211 277 H1
CUP, OIL RESERVOIR
1шт.
5
1302 333 H1
WICK, DRIVE END HOUSING
1шт.
12
1211 285 H1
SEAL, OIL
1шт.
13
1211 286 H1
WASHER, BRAKE
1шт.
18
NSS
WICK, LEVER HOUSING
1шт.
19
NSS
PLUG, WICK
1шт.
20
NSS
BUSHING LEVER HOUSING
1шт.
21
22 411 R1
O-RING, BETWEEN HOUSINGS
1шт.
22
NSS
O-RING, SOLENOID SWITCH
1шт.
23
1211 356 H1
WASHER, SPACER
1шт.
32
19 839 R1
NUT, LOCK - PLUNGER
1шт.
43
1232 885 H1
WASHER, THRUST
1шт.
|$86
1223 263
SCREW AND WASHER, THRU END FRAME TO PLATE
1шт.
49
NSS
O-RING, BETWEEN HOUSINGS
1шт.
53
NSS
WICK, OIL
1шт.
54
NSS
PLUG, WICK
1шт.
55
NSS
BUSHING, END FRAME
1шт.
57
1211 151 H1
GASKET, PLUG
1шт.
|$92
1223 267 H91
PACKAGE, SHIFT LEVER
1шт.
3
347 360 R1
O-RING, BETWEEN HOUSINGS
1шт.
10
213 262 R1
RING, RETAINING
1шт.
14
355 967 R1
O-RING
1шт.
15
352 219 R1
O-RING
1шт.
16
1211 152 H1
SHAFT, SHIFT LEVER
1шт.
17
NSS
LEVER, SHIFT
1шт.
22
NSS
O-RING, SOLENOID SWITCH
1шт.
32
19 839 R1
NUT, LOCK - PLUNGER
1шт.
57
1211 151 H1
GASKET, PLUG
1шт.
|$102
1223 268 H91
PACKAGE, BRUSH
1шт.
45
NSS
PLATE, BRUSH
1шт.
|$104
1223 263 H1
SCREW AND WASHER, THRU END FRAME TO PLATE
6шт.
|$105
1211 292 H1
SCREW, FIELD COIL TO PLATE
4шт.
46
NSS
BRUSH
4шт.
47
NSS
SPRING, BRUSH
4шт.
Выбрано товаров: 108
