Запчасти Komatsu WA500-3L A8-AA ТОПЛИВН. НАСОС КОЖУХ ДВИГАТЕЛЬ

|$0

1296 744 H91

HOUSING, FUEL PUMP

1шт.

1

NSS

BODY, FUEL PUMP

1шт.

2

1238 949 H1

BARREL, GOVERNOR UPPER

1шт.

3

NSS

BARREL, GOVERNOR LOWER

1шт.

4

1238 137 H1

BUSHING, TACHOMETER DRIVE

1шт.

5

1317 094 H1

PIN, ROLL

1шт.

6

6742-01-2480

DOWEL, RING

2шт.

7

1238 613 H1

HOUSING, LOWER SPRING PACK

1шт.

8

1238 170 H1

SLEEVE, SPRING PACK

1шт.

9

1238 991 H1

BOLT

1шт.

|$10

1241 340 H91

PLUNGER, GOVERNOR

1шт.

10

1240 057 H1

DRIVER, GOVERNOR PLUNGER

1шт.

11

1241 339 H1

PLUNGER, GOVERNOR

1шт.

12

1250 107 H1

SPACER, BEARING

1шт.

13

1239 551 H1

BEARING THRUST

1шт.

14

1238 144 H1

SHIM

-2шт.

|$16

1238 145 H1

SHIM

-2шт.

|$17

1238 146 H1

SHIM

-2шт.

15

1239 023 H1

SPRING, TORQUE CONTROL

1шт.

|$19

1237 932 H91

DRIVE, GOVERNOR PLUNGER

1шт.

16

1238 856 H1

PLUNGER, GOVERNOR

1шт.

17

1240 057 H1

DRIVER, GOVERNOR PLUNGER

1шт.

18

1239 683 H1

BEARING, THRUST

1шт.

|$23

1294 268 H91

SHAFT, THROTTLE

1шт.

19

1239 829 H1

SHAFT, THROTTLE

1шт.

20

1239 118 H1

STOP, THROTTLE LEVER

1шт.

21

1239 119 H1

BOLT

2шт.

22

1239 114 H2

BOLT, FUEL PUMP ADJUSTING

1шт.

23

1238 141 H1

SEAL, O-RING

1шт.

24

1238 883 H1

SEAL, O-RING

1шт.

25

1238 887 H1

BALL, PLUG AFC

3шт.

26

1238 978 H1

COVER, FUEL CONTROL

1шт.

27

6560-51-9810

BOLT, DRIVE

2шт.

28

1238 392 H1

RING, RETAINING

1шт.

29

1239 824 H1

BOLT, SOCKET SET

2шт.

30

1250 262 H1

NUT

2шт.

31

1238 338 H1

SCREEN, FILTER

1шт.

32

6560-81-5810

SPRING, COMPRESSION

1шт.

33

1238 591 H1

PLUG, FUEL SCREEN RETURN

1шт.

34

1238 322 H1

SEAL, O-RING

1шт.

35

1238 249 H1

RING, RETAINING

1шт.

36

1238 083 H1

BOLT, DRIVE

4шт.

37

1238 159 H1

NAMEPLATE

1шт.
