Запчасти Komatsu WA500-3L H-A ГИДР. НАСОС. ПОГРУЗ. ГИДРАВЛИКА

|$0

705-22-44070

PUMP ASSEMBLY, LOADER (SAR (4) 160)

SN: A70001 --UP

1шт.

1

705-17-04030

BRACKET

SN: A70001 --UP

1шт.

|$2

705-17-04352

BUSHING, PLANE

SN: A70001 --UP

2шт.

2

705-17-44010

CASE, GEAR

SN: A70001 --UP

1шт.

3

705-17-03352

CARRIER

SN: A70001 --UP

1шт.

|$5

705-17-04352

BUSHING, PLANE

SN: A70001 --UP

2шт.

4

705-17-44410

GEAR, DRIVE

SN: A70001 --UP

1шт.

5

705-17-44510

GEAR, DRIVEN

SN: A70001 --UP

1шт.

6

705-18-04620

PLATE, SIDE

SN: A70001 --UP

2шт.

7

705-17-04471

RING, SEAL

SN: A70001 --UP

2шт.

8

705-17-04441

RING, BACK-UP

SN: A70001 --UP

2шт.

9

705-17-04382

O-RING

SN: A70001 --UP

2шт.

10

04020-01842

PIN, DOWEL

SN: A70001 --UP

4шт.

11

705-17-04670

BOLT

SN: A70001 --UP

4шт.

12

705-17-04740

BOLT

SN: A70001 --UP

4шт.

13

705-17-04980

WASHER, FLAT

SN: A70001 --UP

8шт.

14

705-17-04870

SPACER

SN: A70001 --UP

1шт.

15

704-17-05811

SEAL, OIL

SN: A70001 --UP

1шт.

16

04065-06220

RING, SNAP

SN: A70001 --UP

1шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED ONLY TO DESIGNATED DEALERS THAT ARE APPROVED TO PERFORM HYDRAULIC COMPONENT REBUILD.

20

-1шт.
