Запчасти Komatsu WA500-3L A-AA ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ

1

1307 409 H91

ROD, ENGINE CONNECTING

6шт.

|$1

NSS

ROD, ENGINE CONNECTING

1шт.

2

1310 722 H1

BOLT, CONNECTING ROD CAP

2шт.

3

1307 411 H1

BUSHING

1шт.

4

1307 410 H1

DOWEL, RING

2шт.

5

1307 397 H1

BEARING, CONNECTING ROD (STANDARD)

12шт.

|$6

1307 618 H1

BEARING, CONNECTING ROD (0.010 INCH UNDERSIZE)

12шт.

|$7

1307 619 H1

BEARING, CONNECTING ROD (0.20 INCH UNDERSIZE)

12шт.

|$8

1307 620 H1

BEARING, CONNECTING ROD (0.30 INCH UNDERSIZE)

12шт.

|$9

1307 621 H1

BEARING, CONNECTING ROD (0.40 INCH UNDERSIZE)

12шт.

6

1307 398 H1

PIN, PISTON

6шт.

|$11

1307 425 H1

PISTON KIT, ENGINE

6шт.

7

NSS

PISTON, ENGINE

1шт.

8

1307 399 H1

RING, RETAINING

2шт.

|$14

1310 631 H92

PISTON KIT, ENGINE

6шт.

9

1317 096 H1

RING, COMPRESSION PISTON

6шт.

10

1317 097 H1

RING, COMPRESSION PISTON

6шт.

11

1310 632 H2

RING, OIL PISTON

6шт.

|$18

1307 623 H91

CYLINDER KIT

1шт.

|$19

NSS

LINER, CYLINDER

1шт.

|$20

NSS

PISTON, ENGINE

1шт.

|$21

1307 398 H1

PISTON, ENGINE

1шт.

|$22

1307 399 H1

PIN, PISTON

1шт.

|$23

1238 899 H1

SEAL, O-RING

1шт.

|$24

1239 642 H1

SEAL, O-RING

2шт.

|$25

1310 631 H92

RING SET, PISTON

1шт.
