Запчасти Komatsu WA500-3L A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ

1

1238 831 H1

KEY, RECTANGULAR

1шт.

2

1307 357 H1

GEAR, CRANKSHAFT

1шт.

3

1307 352 H91

CRANKSHAFT, ENGINE

1шт.

4

1239 717 H1

DOWEL, RING

7шт.

|$4

1239 951 H91

BEARING SET, MAIN (STANDARD)

1шт.

5

1239 421 H1

BEARING, MAIN (UPPER 1, 3 AND 5)

3шт.

6

1239 422 H1

BEARING, MAIN (LOWER 1, 3 AND 5)

3шт.

7

1239 423 H1

BEARING, MAIN (UPPER 2, 4 AND 6)

3шт.

8

1239 424 H1

BEARING, MAIN (LOWER 2, 4 AND 6)

3шт.

9

1239 425 H1

BEARING, MAIN (UPPER 7)

1шт.

10

1239 426 H1

BEARING, MAIN (LOWER 7)

1шт.

11

1295 568 H1

BEARING, THRUST

4шт.

12

1295 824 H1

LOCKPLATE

14шт.

|$13

1251 784 H1

SET, MAIN BEARING (0.010 INCH OVERSIZE)

1шт.

|$14

1251 785 H1

SET, MAIN BEARING (0.020 INCH OVERSIZE)

1шт.

|$15

1251 786 H1

SET, MAIN BEARING (0.030 INCH OVERSIZE)

1шт.

|$16

1251 787 H1

SET, MAIN BEARING (0.040 INCH OVERSIZE)

1шт.

|$17

1241 673 H2

BEARING, THRUST (0.010 INCH OVERSIZE)

-2шт.

|$18

1241 674 H2

BEARING, THRUST (0.020 INCH OVERSIZE)

-2шт.

|$19

19

-1шт.

|$20

F1 - PART IS NOT USED ON THIS ENGINE.

20

-1шт.
