Запчасти Komatsu WA500-3L A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

1307 358 H91

BLOCK, CYLINDER

1шт.

1

1239 999 H1

DOWEL, REAR MAIN BEARING

2шт.

2

1240 020 H1

DOWEL, PIN

6шт.

3

1238 624 H1

PIN, ROLL

2шт.

4

1313 147 H1

BOLT (3/4-16x6 5/8 IN)

14шт.

5

1239 152 H1

CAP, MAIN BEARING

1шт.

6

1239 153 H1

CAP, MAIN BEARING

3шт.

7

1239 154 H1

CAP, MAIN BEARING

3шт.

8

1239 258 H1

BUSHING

1шт.

9

1239 558 H1

BUSHING

4шт.

10

1239 560 H1

BUSHING

2шт.

11

1239 822 H1

WASHER, PLAIN (3/4 IN)

14шт.

12

6742-01-5305

WASHER, PLAIN (7/8 IN)

1шт.

13

6216-14-4810

PLUG, PIPE (1/8 NPT)

4шт.

14

1238 839 H1

PLUG, THREADED (7/8 - 18 UNS)

1шт.

15

6732-11-1910

PLUG, PIPE (1/2 NPT)

1шт.

16

1239 259 H1

PLUG, EXPANSION

1шт.

17

6732-21-5540

PLUG, PIPE (3/8 NPT)

3шт.

18

6560-41-4100

PLUG, THREADED (9/16 - 18 UNF)

4шт.

19

6560-51-7710

O-RING

2шт.

20

6560-81-7170

PLUG, THREADED

1шт.

21

6560-81-7730

O-RING

1шт.

22

1246 131 H91

PLUG, THREADED (3/4 - 16 UN)

3шт.

23

6735-21-4160

O-RING

3шт.

24

1307 354 H91

PLUG, THREADED (1 5/8 - 12 UN)

1шт.

25

1307 353 H1

O-RING

1шт.

26

1296 847 H91

PLUG, THREADED (3/8 - 24 UNF)

1шт.

27

1239 669 H1

O-RING

1шт.

28

1296 192 H1

RING, LINER SEAL (0.0205 IN - WHITE)

6шт.

|$29

1295 569 H1

RING, LINER SEAL (0.0195 IN - BLACK)

-2шт.

|$30

1295 570 H1

RING, LINER SEAL (0.0215 IN - ORANGE)

-2шт.

|$31

1239 438 H1

RING, LINER SEAL (0.031 IN)

-2шт.

|$32

1239 439 H1

RING, LINER SEAL (0.062 IN)

-2шт.

29

NSS

BLOCK, CYLINDER

1шт.

30

1267 723 H91

NIPPLE COUPLING

1шт.

31

6560-51-7710

SEAL, O-RING

1шт.

32

1307 355 H1

PIN, ROLL

1шт.

|$37

6731-21-2180

KIT, CYLINDER LINER

6шт.

33

NSS

LINER, CYLINDER

1шт.

34

1238 899 H1

O-RING

1шт.

35

1239 642 H1

O-RING

2шт.

|$41

1239 950 H91

BUSHING KIT, CAMSHAFT

1шт.

|$42

NSS

CAMSHAFT BUSHING KIT, PDC

1шт.

|$43

1239 258 H1

BUSHING

1шт.

|$44

1239 558 H1

BUSHING

4шт.

|$45

1239 560 H1

BUSHING

2шт.
