Запчасти Komatsu WA500-3 КОВШ КАТАЛОГИ ЗЧ

|$$1

4.3M3 BUCKET

-1шт.

|$$2

4.5M3 BUCKET{(WITH SEGMENT EDGE)}

-1шт.

|1

425-70-22101

BUCKET ASS'Y

SN: 50001-UP

1шт.

1

425-70-22111

BUCKET

SN: 50001-UP

1шт.

2

425-70-12321

EDGE (WELDED)

SN: 50001-UP

1шт.

3

425-70-12251

PLATE,L.H. (WELDED)

SN: 50001-UP

1шт.

4

425-70-12261

PLATE,R.H. (WELDED)

SN: 50001-UP

1шт.

5

425-70-22130

PLATE (WELDED)

SN: 50001-UP

2шт.

6

425-70-22180

PLATE (WELDED)

SN: 50001-UP

2шт.

7

425-70-22141

PLATE

SN: 50001-UP

2шт.

8

02090-11685

BOLT

SN: 50001-UP

4шт.

9

02290-11625

NUT

SN: 50001-UP

4шт.

10

01643-22460

WASHER

SN: 50001-UP

4шт.

|$$14

4.7M3 BUCKET

-1шт.

|$$15

5.0M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|11

425-800-2100

BUCKET ASS'Y

SN: 50001-UP

1шт.

11

425-800-2110

BUCKET

SN: 50001-UP

1шт.

12

425-70-12321

EDGE (WELDED)

SN: 50001-UP

1шт.

13

425-70-12251

PLATE,L.H. (WELDED)

SN: 50001-UP

1шт.

14

425-70-12261

PLATE,R.H. (WELDED)

SN: 50001-UP

1шт.

15

425-800-2130

PLATE (WELDED)

SN: 50001-UP

2шт.

16

425-70-22141

PLATE

SN: 50001-UP

2шт.

17

02090-11685

BOLT

SN: 50001-UP

4шт.

18

02290-11625

NUT

SN: 50001-UP

4шт.

19

01643-22460

WASHER

SN: 50001-UP

4шт.
