Запчасти Komatsu WA500-1LE КАРТЕР МАХОВИКА КРЕПЛЕНИЕ ДВИГАТЕЛЯ

1

1295 861 H1

SEAL, OIL

1шт.

2

1295 862 H1

COVER, REAR

1шт.

3

1240 055 H1

COVER, ACCESS HOLE

1шт.

4

1295 251 H1

HOUSING, FLYWHEEL (DRY TYPE)

1шт.

5

1239 211 H1

BOLT (3/8 - 24x1 1/2 INCH)

8шт.

6

1239 962 H2

GASKET, REAR COVER

1шт.

7

1239 244 H1

BOLT (1/4 - 20x 3/4 INCH)

2шт.

8

1239 975 H1

DOWEL, PIN

2шт.

9

1266 424 H1

BOLT (5/8 - 18x1 1/2 INCH)

9шт.

10

1294 114 H1

PLUG, THREADED (3/4 - 16 UNF)(FOR DRY HOUSING ONLY

-2шт.
