Запчасти Komatsu WA500-1LE КОМПРЕССОР АКСЕССУАРЫ

|$0

1239 500 H91

ASSEMBLY, AIR COMPRESSOR

1шт.

|$1

1237 918 H91

CRANKSHAFT, AIR COMPRESSOR

1шт.

1

NSS

CRANKSHAFT, COMPRESSOR

1шт.

2

1295 840 H1

PIPE, PLUG (1/16 NPT)

1шт.

3

1238 099 H1

WASHER, PLAIN (3/8 INCH)

4шт.

4

1307 239 H1

GASKET, SUPPORT

1шт.

5

1238 847 H1

BEARING, THRUST

1шт.

6

1238 974 H1

HUB, SPLINE COUPLING

1шт.

7

1239 100 H1

SUPPORT, AIR COMPRESSOR

1шт.

8

1239 253 H1

BOLT, CAPTIVE WASHER CAP (3/8 - 16x1 3/16 INCH)

4шт.

9

1239 267 H1

BOLT, CAPTIVE WASHER CAP (3/8 - 16x1 1/2 INCH)

2шт.

|$11

1295 137 H91

ASSEMBLY, CRANKCASE

1шт.

10

1238 346 H1

BUSHING

1шт.

11

NSS

CRANKCASE, COMPRESSOR

1шт.

12

1238 366 H1

GASKET, AIR COMPRESSOR

1шт.

13

1295 841 H1

BOLT (5/16 - 18x2 3/4 INCH)

4шт.

14

1238 101 H1

WASHER, LOCK (5/16 INCH)

4шт.

15

1238 112 H1

WASHER, PLAIN (5/16 INCH)

4шт.

16

1238 176 H1

WASHER, PLAIN (1/4 INCH)

2шт.

17

1238 241 H1

SEAL, RECTANGULAR RING

1шт.

18

1238 242 H1

VALVE, EXHAUST

1шт.

19

1238 246 H1

SPRING, COMPRESSION

1шт.

20

1238 248 H1

O-RING

1шт.

21

1238 318 H1

VALVE, INTAKE

1шт.

22

1238 319 H1

SEAT, COMPRESSOR INTAKE VALVE

1шт.

23

1238 364 H1

COVER, AIR COMPRESSOR

1шт.

24

1238 483 H1

PLATE, WEAR

1шт.

25

1238 513 H1

SPRING, VALVE

1шт.

26

1238 516 H1

CAP, UNLOADER VALVE

1шт.

27

1239 460 H1

BOLT (5/16 - 18x3/4 INCH)

2шт.

28

1239 491 H1

SPRING, COMPRESSION

1шт.

29

1294 067 H1

SEAT, COMPRESSOR EXHAUST VALVE

1шт.

30

1239 787 H1

O-RING

1шт.

31

1296 472 H1

HEAD, COMPRESSOR

1шт.

32

1294 069 H1

BODY, UNLOADING VALVE

1шт.

33

1239 832 H1

GASKET, AIR COMPRESSOR

1шт.

34

1238 217 H1

PIN, PISTON

1шт.

35

1307 240 H1

RING, RETAINING

2шт.

36

1239 988 H1

RING, COMPRESSION PISTON

1шт.

37

1238 504 H1

RING, COMPRESSION PISTON

1шт.

38

1238 466 H1

RING, OIL PISTON

1шт.

39

1239 388 H91

ROD, COMPRESSOR CONNECTING

1шт.

|$42

NOT USED

-1шт.

41

1239 814 H1

PISTON, COMPRESSOR

1шт.

42

1307 267 H1

GASKET, AIR COMPRESSOR

1шт.

43

1238 079 H1

NUT, HEAVY HEX (7/16 - 14 UNC)

3шт.

44

1240 031 H1

WASHER, PLAIN (3/8 INCH)

4шт.

45

1238 548 H1

SLEEVE, SPLINE COUPLING

1шт.

46

1294 074 H1

BOLT (7/16 - 14x1 7/8 INCH)

4шт.

47

1239 389 H1

BUSHING

1шт.

|$59

-1шт.

|$51

F1 - 1294 455 H91 KIT, COMPRESSOR VALVE REPAIR

-1шт.

|$52

1238

247 H1 .O-RING (N/I)

-1шт.

|$60

-1шт.

|$54

F2 - 1294 454 H91 KIT, COMPRESSOR HEAD REPAIR (WITHOUT UNLOADER BODY)

-1шт.

|$55

1294 455 H91 .KIT, COMPRESSOR VALVE REPAIR

-1шт.

|$61

-1шт.

|$57

F3 - 1294 453 H91 KIT, COMPRESSOR HEAD REPAIR (WITH UNLOADER BODY)

-1шт.

|$58

1294 455 H91 .KIT, COMPRESSOR VALVE REPAIR

-1шт.
