Запчасти Komatsu WA500-1LE ВОДЯНАЯ ПОМПА СИСТЕМА ОХЛАЖДЕНИЯ

1

1238 934 H1

BELT, WATER PUMP V-RIBBED

1шт.

2

1239 263 H1

BOLT (3/8 - 24x2 1/4 INCH)

4шт.

3

1307 553 H1

BOLT (3/8 - 24x3 1/8 INCH)

2шт.

4

1296 843 H1

GASKET, WATER PUMP

1шт.

5

1238 076 H1

NUT, HEAVY HEX (5/8 - 11 UNC)

1шт.

6

1307 552 H1

BOLT

1шт.

7

1238 872 H1

WASHER, PLAIN (5/8 INCH)

1шт.

|$7

1307 554 H91

PULLEY, IDLER

1шт.

8

1237 999 H1

BOLT (5/16 - 18x3/4 INCH)

1шт.

9

1238 054 H1

RING, RETAINING

1шт.

10

1238 329 H1

O-RING

1шт.

11

1307 558 H1

WASHER, PLAIN (1/4 INCH)

1шт.

12

1307 283 H1

SEAL, OIL

1шт.

13

1307 559 H1

PULLEY, IDLER

1шт.

14

1307 555 H1

COVER, IDLER PULLEY

1шт.

15

1307 556 H1

BEARING, BALL

1шт.

16

1307 557 H1

SHAFT, IDLER

1шт.

|$17

1307 560 H91

KIT, WATER PUMP

1шт.

|$18

NSS

ASSEMBLY, WATER PUMP

1шт.

17

1238 124 H1

PLUG, PIPE (1/8 NPT)

3шт.

18

1238 054 H1

RING, RETAINING

1шт.

19

1239 655 H2

SEAL, WATER PUMP

1шт.

20

1239 739 H1

SEAL, OIL

1шт.

21

1307 561 H91

IMPELLER, WATER PUMP

1шт.

|$24

1307 562 H1

ASSEMBLY, WATER PUMP SHAFT

1шт.

22

1238 540 H1

SPACER, BEARING

1шт.

23

1307 283 H1

SEAL, OIL

1шт.

24

NSS

SHAFT, WATER PUMP

1шт.

25

1307 563 H1

SLINGER, WATER

1шт.

26

1307 556 H1

BEARING, BALL

2шт.

27

1307 566 H1

BODY, WATER PUMP

1шт.

28

1307 564 H91

PULLEY, WATER PUMP

1шт.

|$32

1307 652 H91

KIT, WATER PUMP REPAIR (MAJOR)

1шт.

21

1307 561 H91

IMPELLER, WATER PUMP

1шт.

24

1307 562 H1

SHAFT, WATER PUMP

1шт.

|$35

1307 651 H91

KIT, WATER PUMP REPAIR (MINOR)

1шт.

|$36

1307 651 H91

KIT, WATER PUMP REPAIR (MINOR)

1шт.

18

1238 054 H1

RING, RETAINING

1шт.

|$38

343 909 R1

O-RING

1шт.

|$39

1239 506 H1

GASKET, CONNECTION

1шт.

19

1239 655 H2

SEAL, WATER PUMP

1шт.

4

1296 843 H1

GASKET, WATER PUMP

1шт.
