Запчасти Komatsu WA500-1LE ТОПЛИВН. ПРИВОД НАСОС ТОПЛИВН. СИСТЕМА

|$0

1239 665 H92

ASSEMBLY, GEAR FUEL PUMP

1шт.

|$1

1239 661 H91

PLUG, THREADED

1шт.

1

1239 669 H1

O-RING

1шт.

2

1294 737 H1

PLUG, THREADED (3/8 - 24 UNF)

1шт.

3

1239 985 H1

PIN, ROLL

2шт.

4

1238 185 H1

GASKET, FUEL PUMP

1шт.

5

1238 480 H1

WASHER, LOCK (1/4 INCH)

2шт.

|$7

1239 352 H91

GEAR AND SHAFT

1шт.

6

1238 138 H1

SHAFT, FUEL PUMP DRIVE

1шт.

7

1238 216 H1

GEAR, FUEL PLUMBING

1шт.

|$10

1239 432 H91

GEAR AND SHAFT

1шт.

7

1238 216 H1

GEAR, FUEL PLUMBING

1шт.

8

1238 438 H1

SHAFT, FUEL PUMP

1шт.

9

1239 657 H1

DOWEL, RING

1шт.

10

1240 059 H1

WASHER, PLAIN (1/4 INCH)

2шт.

11

1240 073 H1

BOLT (1/4 - 20x2 1/2 INCH)

2шт.

12

NSS

HOUSING, FUEL PUMP GEAR

1шт.

13

NSS

COVER, FUEL PUMP GEAR

1шт.

14

1239 660 H1

CHECK, VALVE

1шт.

1

1239 669 H1

O-RING

1шт.

15

1250 120 H1

VALVE, PRESSURE REGULATOR

1шт.

16

1239 529 H1

GASKET, FUEL PUMP

1шт.

N/I

1296 798 H1

PLUG, INJECTOR

1шт.
