Запчасти Komatsu WA500-1LE SPRING PACK COVER ТОПЛИВН. СИСТЕМА

|$0

1241 685 H91

COVER, SPRING PACK

1шт.

1

1241 687 H1

COVER, SPRING PACK

1шт.

2

1241 688 H91

PLUG, THREADED

1шт.

3

1239 669 H1

O-RING

1шт.

4

1240 060 H1

GASKET, SPRING PACK

1шт.

|$5

1239 734 H92

PACK, IDLE

1шт.

5

1239 705 H2

GUIDE, IDLE SPRING PLUNGER

1шт.

6

1239 628 H1

SPRING, COMPRESSION

1шт.

7

1240 063 H1

SCREW, KNURLED (12 - 28x1 1/4 INCH)

1шт.

8

1239 406 H1

SPRING, COMPRESSION

1шт.

9

1238 053 H1

RING, RETAINING

2шт.

10

1239 369 H1

BOLT (1/4 - 20x1 1/8 INCH)

2шт.

11

1239 370 H1

BOLT (1/4 - 20x1 1/8 INCH)

2шт.

12

1296 764 H1

PLUNGER, IDLE SPRING

1шт.

13

1239 067 H1

SEAL, WIRE

2шт.

14

1238 629 H1

SPACER, MOUNTING

1шт.

15

1240 062 H1

WASHER, PLAIN (1/8 INCH)

1шт.

16

1240 064 H1

SHIM 0.021 INCH

-2шт.

|$18

1240 065 H1

SHIM 0.010 INCH

-2шт.

|$19

1240 066 H1

SHIM 0.006 INCH

-2шт.

|$20

1238 449 H1

SHIM 0.007 INCH

-2шт.

|$21

1238 511 H1

SHIM 0.010 INCH

-2шт.

17

1296 765 H1

SPRING, COMPRESSION

1шт.
