Запчасти Komatsu WA500-1LE ДВИГАТЕЛЬ МАСЛООХЛАДИТЕЛЬ ДВОЙН. PASS LUBE МАСЛООХЛАДИТЕЛЬ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

1239 115 H1

BOLT (3/8 - 16x7/8 INCH)

2шт.

2

1239 266 H1

BOLT (3/8 - 16x1 3/4 INCH)

2шт.

3

1241 474 H1

HOSE, FLEX

1шт.

4

1246 526 H1

ELBOW, MALE UNION

2шт.

5

1307 367 H1

BOLT (1/2 - 13x1 1/4 INCH)

1шт.

6

1307 277 H1

GASKET, OIL COOLER SUPPORT

1шт.

7

1307 368 H1

BOLT (3/8 - 16x4 3/4 INCH)

4шт.

8

1307 369 H1

BRACKET, OIL COOLER

1шт.

|$8

1307 370 H91

ASSEMBLY, OIL COOLER

1шт.

9

1304 982 H1

O-RING

2шт.

10

1238 773 H1

ADAPTER, FILTER HEAD

1шт.

|$11

1246 118 H91

PLUG, THREADED

5шт.

11

1246 119 H1

O-RING

5шт.

12

1246 120 H1

PLUG, THREADED (9/16 - 18 UNF)

5шт.

13

1241 342 H1

BOLT (3/8 - 16x1 7/8 INCH

10шт.

|$15

1242 131 H91

PLUG, THREADED (3/4 - 16 UNF)

1шт.

14

1246 132 H1

PLUG, THREADED (3/4 - 16 UNF)

1шт.

15

1240 473 H1

O-RING

1шт.

16

1307 371 H1

BOLT (1/4 - 20x1/2 INCH)

1шт.

17

1307 372 H1

SPACER, COOLER SUPPORT

1шт.

18

1307 373 H1

BOLT (5/16 - 18x1 1/8 INCH)

4шт.

19

1307 279 H1

GASKET, LUBE OIL CIR HSG

2шт.

20

1307 374 H1

ADAPTER, O-RING

2шт.

21

1307 375 H1

RETAINER, CONNECTION

1шт.

22

1307 280 H1

GASKET, OIL COOLER SUPPORT

1шт.

23

1295 148 H2

GASKET, FILTER HEAD

1шт.

24

1307 376 H1

VALVE, BYPASS

1шт.

25

1307 377 H1

SPRING, COMPRESSION

1шт.

26

1307 281 H1

GASKET, OIL TRF CONNECTION

1шт.

|$29

1307 378 H1

KIT, OIL COOLER

1шт.

27

1307 379 H1

CONNECTION, OIL TRANSFER

1шт.

28

1307 570 H1

SUPPORT, OIL COOLER

1шт.

29

1307 282 H1

SEAL, RECTANGULAR RING

2шт.

30

1307 380 H91

PLUNGER, BYPASS VALVE

1шт.

|$34

1307 381 H1

PLUG, THREADED

1шт.

31

1241 503 H1

O-RING

1шт.

32

1307 571 H1

PLUG, THREADED

1шт.

33

1307 572 H1

VALVE, SHUTOFF

1шт.

34

1307 384 H1

O-RING

1шт.

35

1307 385 H1

WASHER, PLAIN

1шт.

36

1307 386 H1

THERMOSTAT

1шт.

37

1307 387 H1

COOLER, OIL

1шт.

38

1295 149 H1

HEAD, LUBE OIL FILTER

1шт.
