Запчасти Komatsu WA500-1LE СМАЗЫВ. НАСОС СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

1239 675 H1

BOLT (7/16 - 20x1 3/4 INCH)

3шт.

|$1

1246 118 H91

PLUG, THREADED

1шт.

2

1246 119 H1

O-RING

1шт.

3

1246 120 H1

PLUG, THREADED

1шт.

4

1296 978 H1

BOLT (7/16 - 20x4 1/2 INCH)

2шт.

5

1239 619 H2

GASKET, LUBE OIL PUMP

1шт.

|$6

1307 389 H91

PUMP, LUBRICATING OIL

1шт.

6

1238 322 H1

O-RING

2шт.

7

1238 335 H1

WASHER, PLAIN (3/8 INCH)

1шт.

8

1238 635 H1

PLATE, COVER

1шт.

9

1239 195 H1

SPRING, COMPRESSION

1шт.

10

1239 212 H1

BOLT (3/8 - 16x1 INCH)

2шт.

11

1239 286 H1

PLUG, RETAINER

1шт.

12

1239 322 H1

GASKET, LUBE OIL PUMP COVER

1шт.

13

1239 481 H1

BOLT (5/16 - 18x5/8 INCH)

1шт.

14

1239 482 H1

BOLT (5/16 - 18x1 INCH)

7шт.

|$16

1239 323 H2

GEAR, LUBE OIL PUMP

1шт.

15

1240 015 H1

BUSHING

2шт.

16

NSS

GEAR, LUBE OIL PUMP

1шт.

|$19

1239 324 H92

COVER, LUBE OIL PUMP

1шт.

17

1240 036 H1

BUSHING

1шт.

18

NSS

COVER, LUBE OIL PUMP

1шт.

19

6736-51-9110

GASKET, HYDRAULIC PUMP

1шт.

|$23

1307 391 H91

PUMP, LUBRICATING OIL

1шт.

20

1239 279 H1

SHAFT, IDLER

1шт.

21

1239 318 H1

WASHER, PLAIN (3/4 INCH)

1шт.

22

1239 319 H1

DISC, VALVE

1шт.

23

1239 320 H1

SPRING, COMPRESSION

1шт.

24

1295 894 H1

GEAR, LUBE OIL PUMPING

1шт.

25

1239 280 H1

SHAFT, LUBE OIL PUMP

1шт.

26

1307 392 H1

GEAR, LUBRICATING OIL PUMP

1шт.

27

1307 393 H1

PLUG, RETAINER

1шт.

|$32

1267 842 H1

BODY, LUBRICATING OIL PUMP

1шт.

28

NSS

BODY, LUBRICATING OIL PUMP

1шт.

17

1240 036 H1

BUSHING

2шт.

29

1295 893 H1

PLUNGER, PRESSURE REGULATOR

1шт.
