Запчасти Komatsu WA500-1LC FIG. E-A ЭЛЕКТРИКА - ПЕРЕДН. ОСВЕЩЕНИЕ КРЕПЛЕНИЕ ЭЛЕКТРИКА

1

425-06-13112

SUPPORT, L.H. - FRONT LIGHTS

SN: A60001-UP-UP

1шт.

2

425-06-13122

SUPPORT, R.H. - FRONT LIGHTS

SN: A60001-UP-UP

1шт.

3

01010-81225

BOLT - SUPPORT MOUNTING

SN: A60001-UP-UP

8шт.

4

01643-31232

WASHER

SN: A60001-UP-UP

8шт.

5

419-06-13221

BRACKET, L.H. - FRONT LIGHTS

SN: A60001-UP-UP

1шт.

6

419-06-13231

BRACKET, R.H. - FRONT LIGHTS

SN: A60001-UP-UP

1шт.

7

01010-31225

BOLT - BRACKET MOUNTING

SN: A60001-UP-UP

6шт.

8

01643-31232

WASHER

SN: A60001-UP-UP

6шт.

9

08037-03614

GROMMET

SN: A60001-UP-UP

2шт.

10

LIGHT - FRONT DRIVING(SEE FIG. E0301-01A0)

SN: A60001-UP-UP

2шт.

11

419-06-13250

COVER, FRONT - DRIVING LIGHT

SN: A60001-UP-UP

2шт.

12

01010-80612

BOLT - FRONT COVER MOUNTING

SN: A60001-UP-UP

8шт.

13

01643-30623

WASHER

SN: A60001-UP-UP

8шт.

14

LIGHT, L.H. - TURN SIGNAL AND PARKING (SEE FIG. E0302-01A0)

SN: A60001-UP-UP

1шт.

15

LIGHT, R.H. - TURN SIGNAL AND PARKING (SEE FIG. E0303-01A0)

SN: A60001-UP-UP

1шт.

16

01220-40520

SCREW - TURN SIGNAL AND PARKINGLIGHT MOUNTING

SN: A60001-UP-UP

8шт.

17

01601-20513

WASHER, LOCK

SN: A60001-UP-UP

8шт.

18

421-06-12360

HARNESS - FRONT LAMPS

SN: A60001-UP-UP

2шт.

19

419-06-13241

COVER, REAR - FRONT DRIVING LIGHT

SN: A60001-UP-UP

2шт.

20

01010-80612

BOLT - REAR COVER MOUNTING

SN: A60001-UP-UP

8шт.

21

01643-30623

WASHER

SN: A60001-UP-UP

8шт.

22

08037-02512

GROMMET

SN: A60001-UP-UP

2шт.
