Запчасти Komatsu WA500-1LC FIG. E-A ЭЛЕКТРИКА - ПАНЕЛЬ ПРИБОРОВ ЭЛЕКТРИКА

1

01225-40620

SCREW

SN: A60001-UP-UP

6шт.

2

23S-06-13270

LAMP ASSEMBLY

SN: A60001-UP-UP

1шт.

|$2

08110-12410

BULB - 12 W

SN: A60001-UP-UP

1шт.

3

412-06-15321

GROMMET

SN: A60001-UP-UP

2шт.

4

421-06-15330

SCREW - LAMP MOUNTING

SN: A60001-UP-UP

2шт.

5

421-06-15340

WASHER

SN: A60001-UP-UP

2шт.

6

421-06-11552

SWITCH - TRANSMISSION CUT-OFF

SN: A60001-UP-UP

1шт.

|$7

01580-60403

NUT

SN: A60001-UP-UP

1шт.

7

09415-00706

CAP

SN: A60001-UP-UP

4шт.

8

421-06-11512

SWITCH - PARKING BRAKE

SN: A60001-UP-UP

1шт.

9

421-06-11521

SWITCH - WORK LAMP

SN: A60001-UP-UP

1шт.

10

08086-10000

SWITCH, STARTING - WITH KEYS

SN: A60001-UP-UP

1шт.

|$13

OR

-1шт.

10

08086-20000

SWITCH, STARTING - WITH KEYS

SN: A60001-UP-UP

1шт.

|$16

01601-20513

WASHER

SN: A60001-UP-UP

1шт.

|$17

01580-60403

NUT

SN: A60001-UP-UP

1шт.

11

421-06-11692

HARNESS - STARTING SWITCH

SN: A60001-UP-UP

1шт.

12

08038-00518

CAP - STARTING SWITCH

SN: A60001-UP-UP

4шт.

13

01435-00620

BOLT

SN: A60001-UP-UP

2шт.

14

424-06-12240

CONNECTOR

SN: A60001-UP-UP

1шт.

15

08034-20536

STRAP, TIE

SN: A60001-UP-UP

1шт.

16

421-06-12610

CLIP

SN: A60001-UP-UP

2шт.

17

238-06-17130

CLIP

SN: A60001-UP-UP

1шт.

18

01220-40608

SCREW

SN: A60001-UP-UP

3шт.

19

01641-20608

WASHER

SN: A60001-UP-UP

3шт.

20

421-09-11930

GROMMET

SN: A60001-UP-UP

1шт.

21

421-06-11561

SWITCH - SPARE

SN: A60001-UP-UP

1шт.

22

418-06-11410

SWITCH - ETHER START

SN: A60001-UP-UP

1шт.

23

08037-03614

GROMMET

SN: A60001-UP-UP

1шт.

24

HARNESS - FLOOR LINE(SEE FIG. E0200-03A0)

SN: A60001-UP-UP

1шт.

25

MONITOR PANEL - MACHINES WITH GROUND DRIVEN STEERING (SEE FIG. K4210-02A0)

SN: A60001-UP-UP

1шт.

|$34

OR

-1шт.

25

MONITOR PANEL - NO GROUND DRIVENSTEERING (SEE FIG. K4210-01A0)

SN: A60001-UP-UP

1шт.
