Запчасти Komatsu WA500-1LC FIG. D-A ТОПЛ. БАК И ТОПЛИВОПРОВОД ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

425-04-11210

TANK - FUEL

SN: A60001-UP-UP

1шт.

|$1

01010-32465

BOLT - TANK MOUNTING, FRONT

SN: A60001-UP-UP

2шт.

|$2

01010-32470

BOLT - TANK MOUNTING, REAR

SN: A60001-UP-UP

2шт.

|$3

01643-32460

WASHER

SN: A60001-UP-UP

4шт.

2

428-04-11120

COVER

SN: A60001-UP-UP

2шт.

|$5

01435-01025

BOLT - COVER MOUNTING

SN: A60001-UP-UP

12шт.

3

07000-05200

O-RING, COVER

SN: A60001-UP-UP

2шт.

4

423-04-11362

CAP, FUEL TANK - LOCKABLE

SN: A60001-UP-UP

1шт.

5

417-04-21230

PACKING

SN: A60001-UP-UP

1шт.

|$9

08086-10000

KEY, FUEL CAP

SN: A60001-UP-UP

1шт.

|$11

OR

-1шт.

|$13

08086-20000

KEY, FUEL CAP

SN: A60001-UP-UP

1шт.

6

07056-18416

STRAINER - FUEL TANK

SN: A60001-UP-UP

1шт.

|$15

426-04-11310

COVER

SN: A60001-UP-UP

1шт.

|$16

426-04-11141

COVER

SN: A60001-UP-UP

1шт.

|$17

421-04-11191

GASKET

SN: A60001-UP-UP

2шт.

7

425-04-11161

COVER - FUEL CAP

SN: A60001-UP-UP

1шт.

|$19

01435-01020

BOLT - FUEL CAP COVER

SN: A60001-UP-UP

2шт.

8

421-09-12321

HOLDER - FUEL CAP

SN: A60001-UP-UP

1шт.

|$21

01220-40508

SCREW - HOLDER

SN: A60001-UP-UP

2шт.

|$22

01220-40512

SCREW - HOLDER

SN: A60001-UP-UP

3шт.

|$23

01641-20508

WASHER

SN: A60001-UP-UP

5шт.

9

416-04-10131

VALVE - FUEL TANK DRAIN

SN: A60001-UP-UP

1шт.

10

419-04-11120

COVER - DRAIN VALVE

SN: A60001-UP-UP

1шт.

|$26

01435-00816

BOLT - DRAIN VALVE COVER

SN: A60001-UP-UP

2шт.

11

7861-91-4820

SENSOR - FUEL LEVEL

SN: A60001-UP-UP

1шт.

|$28

01435-01014

BOLT - FUEL SENSOR MOUNTING

SN: A60001-UP-UP

4шт.

12

07000-02085

O-RING - FUEL LEVEL SENSOR

SN: A60001-UP-UP

1шт.

13

04434-50610

CLIP - FUEL SENSOR HARNESS

SN: A60001-UP-UP

3шт.

|$31

01435-01016

BOLT - HARNESS CLIP

SN: A60001-UP-UP

3шт.

14

08052-11711

CLIP - FUEL SENSOR HARNESS

SN: A60001-UP-UP

1шт.

|$33

01435-01016

BOLT - HARNESS CLIP

SN: A60001-UP-UP

1шт.

15

423-09-12120

CONNECTOR - VENT PORT

SN: A60001-UP-UP

1шт.

16

425-04-11220

TUBE - FUEL TANK VENT

SN: A60001-UP-UP

1шт.

17

424-04-11120

CLIP - VENT TUBE

SN: A60001-UP-UP

1шт.

|$37

01010-81020

BOLT - VENT TUBE CLIP

SN: A60001-UP-UP

1шт.

|$38

01643-31032

WASHER - M10

SN: A60001-UP-UP

1шт.

18

02750-24100

HOSE - FUEL SUCTION LINE

SN: A60001-UP-UP

1шт.

19

154-04-12680

CONNECTOR - FUEL SUCTION PORT

1шт.

20

566-04-11280

CONNECTOR - FUEL RETURN PORT

SN: A60001-UP-UP

1шт.

21

425-04-14131

HOSE - FUEL RETURN LINE

1шт.

22

42A-16-11231

BRACKET - HOSE CLAMP MOUNTING

SN: A60001-UP-UP

1шт.

|$44

02010-70632

BOLT - BRACKET MOUNTING

1шт.

|$45

01641-21016

WASHER

SN: A60001-UP-UP

1шт.

23

424-09-12550

CLAMP - RETURN LINE HOSE

SN: A60001-UP-UP

2шт.

24

421-09-12170

CLAMP - SUCTION LINE HOSE

SN: A60001-UP-UP

2шт.

|$48

01010-81065

BOLT - RETURN LINE AND SUCTION LINEHOSE CLAMPS

SN: A60001-UP-UP

2шт.

N/I

421-62-14680

SPACER

SN: A60001-UP-UP

1шт.
