Запчасти Komatsu WA500-1LC FIG. A-A ВЫПУСКНОЙ КОЛЛЕКТОР ДВИГАТЕЛЬ

1

1238 846 H1

CONNECTION - AIR CROSSOVER

SN: A60001-UP-UP

1шт.

2

102 647 H45

BOLT

SN: A60001-UP-UP

4шт.

3

1238 117 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

4

1240 047 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

5

1238 824 H1

CLAMP - T-BOLT

SN: A60001-UP-UP

2шт.

6

1238 912 H1

GASKET - CONNECTION

SN: A60001-UP-UP

1шт.

7

1266 434 H1

HOSE - PLAIN

SN: A60001-UP-UP

1шт.

8

1238 158 H1

DOWEL, PIN

SN: A60001-UP-UP

6шт.

9

1239 458 H1

GASKET - EXHAUST MANIFOLD

SN: A60001-UP-UP

6шт.

10

1239 781 H1

BOLT - FLANGE

SN: A60001-UP-UP

12шт.

11

1296 594 H1

GASKET - EXHAUST MANIFOLD

SN: A60001-UP-UP

1шт.

12

1267 649 H1

NUT, HEX FLANGE

SN: A60001-UP-UP

4шт.

13

1239 525 H1

MANIFOLD, EXHAUST

SN: A60001-UP-UP

1шт.

14

1239 615 H1

MANIFOLD, EXHAUST

SN: A60001-UP-UP

1шт.

15

1239 616 H1

MANIFOLD, EXHAUST

SN: A60001-UP-UP

1шт.

16

1267 648 H1

STUD

SN: A60001-UP-UP

4шт.

17

1238 012 H1

BOLT

SN: A60001-UP-UP

3шт.

18

1240 089 H1

COVER - HAND HOLE

SN: A60001-UP-UP

1шт.

19

1238 081 H1

NUT - HEAVY HEX

SN: A60001-UP-UP

3шт.

20

1238 101 H1

WASHER, LOCK

SN: A60001-UP-UP

2шт.

21

1238 112 H1

WASHER, PLAIN

SN: A60001-UP-UP

6шт.

22

1240 032 H1

CLIP

SN: A60001-UP-UP

1шт.

23

1238 161 H1

CLIP

SN: A60001-UP-UP

1шт.

24

1238 174 H1

CLIP

SN: A60001-UP-UP

3шт.

25

1240 023 H1

ELBOW - MALE ADAPTER

SN: A60001-UP-UP

1шт.

26

1241 964 H1

HOSE - FLEXIBLE

SN: A60001-UP-UP

1шт.

27

140 483 H

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

28

1246 526 H1

ELBOW - MALE UNION

SN: A60001-UP-UP

1шт.

29

1295 932 H1

ELBOW - MALE UNION

SN: A60001-UP-UP

1шт.

30

1241 371 H1

GASKET - OIL DRAIN

SN: A60001-UP-UP

1шт.

31

1295 933 H1

CONNECTION - TURBOCHARGER OIL DRAIN

SN: A60001-UP-UP

1шт.
