Запчасти Komatsu WA500-1LC FIG. B-A ДАТЧИК УР-НЯ МАСЛА ЛИНИЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

425-06-15130

BRACKET - SENSOR HOUSING

SN: A60001-UP-UP

1шт.

|$1

25 770 R1

BOLT, BRACKET MOUNTING -3/8 NF X 3/4 IN.

SN: A60001-UP-UP

2шт.

|$2

01641-21016

WASHER

SN: A60001-UP-UP

2шт.

2

6210-81-4210

HOUSING - OIL LEVEL SENSOR

SN: A60001-UP-UP

1шт.

|$4

25 500 R1

BOLT, HOUSING - 3/8 NC X 3 1/4 IN.

SN: A60001-UP-UP

2шт.

|$5

01641-21016

WASHER

SN: A60001-UP-UP

2шт.

3

7861-91-4500

SENSOR, ENGINE OIL LEVEL

SN: A60001-UP-UP

1шт.

|$7

252 483 R1

O-RING, SENSOR

SN: A60001-UP-UP

1шт.

4

1239 408 H1

CONNECTER - AT OIL PAN

SN: A60001-UP-UP

1шт.

5

1296 838 H1

ADAPTER

SN: A60001-UP-UP

1шт.

N/I

1238 130 H1

ADAPTER

SN: A60001-UP-UP

1шт.

6

1296 836 H1

HOSE - OIL PAN TO SENSOR HOUSING

SN: A60001-UP-UP

1шт.

7

1296 837 H1

ADAPTER - AT SENSOR HOUSING

SN: A60001-UP-UP

1шт.

N/I

1294 334 H1

SEAL

SN: A60001-UP-UP

1шт.

8

1239 408 H1

ADAPTER - AT CRANKCASE

SN: A60001-UP-UP

1шт.

9

425-06-15120

BUSHING

SN: A60001-UP-UP

1шт.

10

1296 835 H1

HOSE - SENSOR HOUSING TO CRANKCASE

SN: A60001-UP-UP

1шт.

11

1296 837 H1

ADAPTER - AT SENSOR HOUSING

SN: A60001-UP-UP

1шт.

N/I

1294 334 H1

SEAL

SN: A60001-UP-UP

1шт.

|$19

-1шт.

|$21

-1шт.
