Запчасти Komatsu WA500-1LC FIG. B-A ВОЗДУХООЧИСТИТЕЛЬ, ГЛУШИТЕЛЬ, И СОЕДИН-ЕS КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

AIR CLEANER ASSEMBLY(SEE FIG. B0301-01A0)

SN: A60001-UP-UP

1шт.

2

601-181-5710

PRE-CLEANER

SN: A60001-UP-UP

1шт.

3

6127-11-4360

BAND - AIR CLEANER MOUNTING

SN: A60001-UP-UP

2шт.

|$3

6643-11-4641

BOLT

SN: A60001-UP-UP

2шт.

4

425-01-A1311

BRACKET - AIR CLEANER MOUNTING

SN: A60001-UP-UP

1шт.

|$5

25 962 R1

BOLT, BRACKET MOUNTING -1/2 NC X 6 3/4 IN.

SN: A60001-UP-UP

2шт.

|$6

120 384

WASHER, LOCK - 1/2 IN.

SN: A60001-UP-UP

2шт.

|$7

25 338 R1

BOLT, BRACKET MOUNTING -5/8 NF X 2 1/2 IN.

SN: A60001-UP-UP

1шт.

|$8

121 574

WASHER, LOCK - 5/8 IN.

SN: A60001-UP-UP

2шт.

5

425-01-A1330

TUBE - AIR INLET

SN: A60001-UP-UP

1шт.

|$10

6127-81-4823

GASKET - AIR INLET TUBE

SN: A60001-UP-UP

1шт.

6

690 069 C1

CLAMP

SN: A60001-UP-UP

4шт.

7

605 168 C2

ELBOW, RUBBER

SN: A60001-UP-UP

1шт.

8

425-01-A1320

TUBE

SN: A60001-UP-UP

1шт.

9

984 288 R91

ELBOW - RUBBER

SN: A60001-UP-UP

1шт.

10

NSS

ELBOW

SN: A60001-UP-UP

1шт.

11

NSS

CONNECTOR

SN: A60001-UP-UP

2шт.

12

NSS

CLAMP - HOSE

SN: A60001-UP-UP

2шт.

13

08671-50160

HOSE - SERVICE INDICATOR

SN: A60001-UP-UP

1шт.

14

08670-02001

INDICATOR - AIR CLEANER SERVICE

SN: A60001-UP-UP

1шт.

15

04434-51410

CLAMP - HOSE

SN: A60001-UP-UP

4шт.

|$21

01435-01016

BOLT - CLAMP MOUNTING

SN: A60001-UP-UP

4шт.

16

08037-01610

GROMMET

SN: A60001-UP-UP

1шт.

17

425-02-A1014

MUFFLER

SN: A60001-UP-UP

1шт.

|$24

24 862 R1

BOLT, MUFFLER TO BRACKET MOUNTING -1/2 NC X 1 1/2 IN.

SN: A60001-UP-UP

4шт.

|$25

25 536 R1

WASHER, FLAT - 1/2 IN.

SN: A60001-UP-UP

8шт.

|$26

120 384

WASHER, LOCK - 1/2 IN.

SN: A60001-UP-UP

4шт.

|$27

25 526 R1

NUT - 1/2 NC

SN: A60001-UP-UP

4шт.

|$28

702 327 C91

CLAMP - MUFFLER TO TURBOCHARGER

SN: A60001-UP-UP

1шт.

|$29

275 804 R1

BOLT, CLAMP - 3/8 NC X 3 IN.

SN: A60001-UP-UP

1шт.

|$30

25 544 R1

WASHER, FLAT - 3/8 IN.

SN: A60001-UP-UP

2шт.

|$31

9413 979

NUT, LOCK - 3/8 NC

SN: A60001-UP-UP

1шт.

18

425-02-A1220

BRACKET - MUFFLER MOUNTING

SN: A60001-UP-UP

1шт.

|$33

120 384

WASHER, LOCK - 1/2 IN.

SN: A60001-UP-UP

4шт.

|$34

24 870 R1

BOLT, BRACKET MOUNTING -1/2 NC X 5 IN.

2шт.

|$35

25 962 R1

BOLT, BRACKET MOUNTING -1/2 NC X 6 3/4 IN.

SN: A60001-UP-UP

2шт.

19

425-01-A1340

TUBE, ASPIRATOR - MUFFLER SIDE

1шт.

20

425-01-A1351

TUBE, ASPIRATOR - AIR CLEANER SIDE

SN: A60001-UP-UP

1шт.

21

108 575

CLAMP - ASPIRATOR TUBES

2шт.

22

425-01-A1390

HOSE - ASPIRATOR LINE

SN: A60001-UP-UP

2шт.

23

690 062 C1

CLAMP - HOSE

SN: A60001-UP-UP

4шт.

24

425-01-A1380

VALVE - CHECK

SN: A60001-UP-UP

1шт.

25

425-02-A1030

BRACKET - CHECK VALVE MOUNTING

SN: A60001-UP-UP

1шт.

26

425-02-A1050

SPACER

SN: A60001-UP-UP

1шт.

27

391 156 R1

CLAMP - CHECK VALVE

SN: A60001-UP-UP

1шт.

|$45

25 678 R1

BOLT - 5/16 NC X 3 1/4 IN.

SN: A60001-UP-UP

1шт.

|$46

25 533 R1

WASHER, FLAT - 5/16 IN.

SN: A60001-UP-UP

2шт.

|$47

25 520 R1

NUT - 5/16 NC

SN: A60001-UP-UP

1шт.

28

425-02-A1041

TUBE - MUFFLER DRAIN

SN: A60001-UP-UP

1шт.

29

9402 708

FITTING

SN: A60001-UP-UP

1шт.

|$50

444 028

BUSHING - REDUCER

SN: A60001-UP-UP

1шт.

30

279 025 R91

CLAMP - HOSE

SN: A60001-UP-UP

1шт.

31

07287-01014

HOSE - MUFFLER DRAIN

SN: A60001-UP-UP

1шт.

32

08036-01414

CLIP - HOSE

SN: A60001-UP-UP

1шт.

|$54

24 839 R1

BOLT - 3/8 NC X 3/4 IN.

SN: A60001-UP-UP

1шт.

|$55

25 534 R1

WASHER, FLAT - 3/8 IN.

SN: A60001-UP-UP

1шт.

|$56

-1шт.

|$58

-1шт.
