Запчасти Komatsu WA500-1LC FIG. A-A ТРУБОПРОВОД ВПУСКА ВОЗДУХА ДВИГАТЕЛЬ

1

1238 079 H1

NUT - HEAVY HEX

SN: A60001-UP-UP

1шт.

2

1238 970 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.

3

1239 274 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

1шт.

4

1240 047 H1

PLUG - PIPE

SN: A60001-UP-UP

1шт.

5

1239 164 H1

GASKET - INTAKE MANIFOLD

SN: A60001-UP-UP

3шт.

6

1295 896 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

3шт.

7

1239 585 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

6шт.

8

1238 898 H1

GASKET - WATER TRANSFER CONNECTION

SN: A60001-UP-UP

1шт.

9

1239 292 H1

CONNECTION - WATER OUTLET

SN: A60001-UP-UP

1шт.

10

1239 332 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

3шт.

11

1238 070 H1

BOLT

SN: A60001-UP-UP

2шт.

12

1238 100 H1

WASHER, LOCK

SN: A60001-UP-UP

2шт.

13

1238 115 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

14

1238 644 H1

CLIP

SN: A60001-UP-UP

2шт.

15

1241 967 H1

CLAMP - HOSE

SN: A60001-UP-UP

4шт.

16

1239 570 H1

TUBE - WATER TRANSFER

SN: A60001-UP-UP

1шт.

17

1295 897 H1

HOSE - PLAIN

SN: A60001-UP-UP

2шт.

|$17

1239 708 H91

AFTERCOOLER

SN: A60001-UP-UP

1шт.

18

1238 533 H1

O-RING

SN: A60001-UP-UP

4шт.

19

1238 911 H2

GASKET - AFTERCOOLER COVER

SN: A60001-UP-UP

1шт.

20

1239 106 H1

BOLT - FLANGE

SN: A60001-UP-UP

24шт.

21

1239 266 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

22

1239 586 H2

CORE - AFTERCOOLER

SN: A60001-UP-UP

1шт.

23

1239 602 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

8шт.

24

1266 426 H1

CONNECTION - WATER INLET

SN: A60001-UP-UP

1шт.

25

1239 632 H1

GASKET - WATER TRANSFER CONNECTION

SN: A60001-UP-UP

1шт.

|$26

1239 710 H91

MANIFOLD - AIR INTAKE

SN: A60001-UP-UP

1шт.

26

NSS

MANIFOLD - AIR INTAKE

SN: A60001-UP-UP

1шт.

27

1239 014 H1

SCREW - SELF-TAPPING METAL

SN: A60001-UP-UP

8шт.

28

1266 427 H1

PLATE - COVER

SN: A60001-UP-UP

2шт.

29

1266 428 H1

O-RING

SN: A60001-UP-UP

2шт.

30

1239 818 H1

COVER - AFTERCOOLER

SN: A60001-UP-UP

1шт.

31

1238 008 H1

BOLT

SN: A60001-UP-UP

1шт.

32

25 522 R1

NUT - HEAVY HEX

SN: A60001-UP-UP

1шт.

33

1238 099 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

34

120 382

WASHER, LOCK

SN: A60001-UP-UP

1шт.

35

1241 967 H1

CLAMP - HOSE

SN: A60001-UP-UP

4шт.

36

1238 161 H1

CLIP

SN: A60001-UP-UP

1шт.

37

1239 386 H1

TUBE - WATER TRANSFER

SN: A60001-UP-UP

1шт.

38

1295 897 H1

HOSE - PLAIN

SN: A60001-UP-UP

2шт.

39

1239 689 H1

BRACE - TUBE

SN: A60001-UP-UP

1шт.
