Запчасти Komatsu WA500-1LC FIG. A7-A ЛИНИЯ КОМПРЕССОРА ДВИГАТЕЛЬ

1

1238 007 H1

BOLT

SN: A60001-UP-UP

1шт.

2

1238 101 H1

WASHER, LOCK

SN: A60001-UP-UP

1шт.

3

1238 537 H2

CONNECTION - AIR COMPRESSOR INLET

SN: A60001-UP-UP

1шт.

4

1239 482 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

1шт.

5

1239 916 H1

GASKET - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

6

1238 937 H1

TUBE - COMPRESSOR AIR INLET

SN: A60001-UP-UP

1шт.

7

1239 024 H1

COUPLING - ELBOW HOSE

SN: A60001-UP-UP

1шт.

8

1241 967 H1

CLAMP, HOSE

SN: A60001-UP-UP

4шт.

9

1295 844 H1

HOSE - PLAIN

SN: A60001-UP-UP

2шт.

10

1238 503 H1

ADAPTER, PLAIN

SN: A60001-UP-UP

1шт.

11

1237 980 H1

ELBOW - MALE ADAPTER

SN: A60001-UP-UP

1шт.

12

1239 731 H1

TUBE - COMPRESSOR WATER OUTLET

SN: A60001-UP-UP

1шт.

13

1237 975 H1

CONNECTOR - MALE

SN: A60001-UP-UP

1шт.

|$13

1240 047 H1

PLUG - FUEL PUMP DRAIN

SN: A60001-UP-UP

1шт.
