Запчасти Komatsu WA500-1LC FIG. A7-A КОМПРЕССОР ДВИГАТЕЛЬ

1

1238 079 H1

NUT - HEAVY HEX

SN: A60001-UP-UP

2шт.

2

1238 108 H1

WASHER, LOCK

SN: A60001-UP-UP

2шт.

3

1240 031 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

4

1238 548 H1

SLEEVE - SPLINE COUPLING

SN: A60001-UP-UP

1шт.

5

1238 759 H1

BOLT

SN: A60001-UP-UP

2шт.

6

1239 331 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

7

1239 733 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

1шт.

8

1295 838 H1

NUT - HEX FLANGE

SN: A60001-UP-UP

1шт.

9

1242 050 H1

GASKET - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

10

1294 586 H1

GASKET - FUEL PUMP

SN: A60001-UP-UP

1шт.

11

1295 839 H1

BRACE - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

12

1294 074 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.

|$12

1239 500 H91

COMPRESSOR, AIR

SN: A60001-UP-UP

1шт.

13

1239 832 H1

GASKET - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

14

1294 069 H1

BODY - UNLOADING VALVE

SN: A60001-UP-UP

1шт.

15

1239 814 H1

PISTON, COMPRESSOR

SN: A60001-UP-UP

1шт.

16

1294 068 H1

HEAD, COMPRESSOR

SN: A60001-UP-UP

1шт.

17

1239 787 H1

O-RING

SN: A60001-UP-UP

1шт.

18

1294 067 H1

SEAT - COMPRESSOR EXHAUST VALVE

SN: A60001-UP-UP

1шт.

19

1239 491 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

20

1239 460 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

21

1239 267 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

22

140 483 H

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.

23

1239 099 H1

SUPPORT - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

24

1238 974 H1

HUB - SPLINE COUPLING

SN: A60001-UP-UP

1шт.

25

1238 971 H1

CRANKSHAFT, COMPRESSOR

SN: A60001-UP-UP

1шт.

26

1239 988 H1

RING - COMPRESSION PISTON

SN: A60001-UP-UP

1шт.

27

1295 840 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

28

1238 847 H1

BEARING, THRUST

SN: A60001-UP-UP

1шт.

29

1238 516 H1

CAP - UNLOADER VALVE

SN: A60001-UP-UP

1шт.

30

1238 513 H1

SPRING, VALVE

SN: A60001-UP-UP

1шт.

31

1238 504 H1

RING - COMPRESSION PISTON

SN: A60001-UP-UP

1шт.

32

1238 483 H1

PLATE - AIR COMPRESSOR WEAR

SN: A60001-UP-UP

1шт.

33

1238 466 H1

RING - OIL PISTON

SN: A60001-UP-UP

1шт.

|$34

1295 137 H91

CRANKCASE, COMPRESSOR

SN: A60001-UP-UP

1шт.

34

1238 346 H1

BUSHING

SN: A60001-UP-UP

1шт.

35

NSS

CRANKCASE, COMPRESSOR

SN: A60001-UP-UP

1шт.

36

1295 841 H1

BOLT

SN: A60001-UP-UP

4шт.

37

1238 099 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

38

1238 101 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

39

1238 112 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

40

1294 071 H1

NAMEPLATE

SN: A60001-UP-UP

1шт.

41

1295 842 H1

SCREW, DRIVE

SN: A60001-UP-UP

2шт.

42

1238 176 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

43

1238 217 H1

PIN, PISTON

SN: A60001-UP-UP

1шт.

44

1238 218 H1

RING, RETAINING

SN: A60001-UP-UP

2шт.

45

1238 241 H1

SEAL - RECTANGULAR RING

SN: A60001-UP-UP

1шт.

46

1238 242 H1

VALVE, EXHAUST

SN: A60001-UP-UP

1шт.

47

1238 246 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

48

1238 248 H1

O-RING

SN: A60001-UP-UP

1шт.

49

1238 318 H1

VALVE, INTAKE

SN: A60001-UP-UP

1шт.

50

1238 319 H1

SEAT - COMPRESSOR INTAKE VALVE

SN: A60001-UP-UP

1шт.

51

1238 364 H1

COVER, COMPRESSOR

SN: A60001-UP-UP

1шт.

52

1238 366 H1

GASKET - AIR COMPRESSOR

SN: A60001-UP-UP

1шт.

53

1295 135 H1

GASKET, SUPPORT

SN: A60001-UP-UP

1шт.

54

1239 388 H91

ROD, CONNECTING - COMPRESSOR

SN: A60001-UP-UP

1шт.

|$56

1295 164 H1

ROD, CONNECTING

SN: A60001-UP-UP

1шт.

|$57

1239 389 H1

BUSHING

SN: A60001-UP-UP

1шт.

55

1237 975 H1

CONNECTOR, MALE

SN: A60001-UP-UP

1шт.

56

1237 980 H1

ELBOW - MALE ADAPTER

SN: A60001-UP-UP

1шт.

57

1258 630 H1

TUBE - COMPRESSOR WATER INLET

SN: A60001-UP-UP

1шт.
