Запчасти Komatsu WA500-1LC FIG. A-A СТАРТЕР ДВИГАТЕЛЬ

|$0

1222 960 H91

MOTOR ASSEMBLY - CRANKING

SN: A60001-UP-UP

1шт.

|$1

1228 448 H91

HOUSING ASSEMBLY - DRIVE END

SN: A60001-UP-UP

1шт.

1

1211 288 H1

BUSHING - DRIVE END

SN: A60001-UP-UP

1шт.

2

347 360 R1

O-RING - BETWEEN HOUSINGS

SN: A60001-UP-UP

1шт.

3

1211 277 H1

CUP - OIL RESERVOIR

SN: A60001-UP-UP

1шт.

4

NSS

WICK, OIL

SN: A60001-UP-UP

1шт.

5

NSS

HOUSING - DRIVE END

SN: A60001-UP-UP

1шт.

|$7

21 241 R1

BOLT - MOUNTING

SN: A60001-UP-UP

6шт.

6

1228 455 H1

PLUG, CUP - REMAINING HOUSING BOLT HOLES

SN: A60001-UP-UP

-2шт.

7

1223 259 H1

DRIVE, MOTOR

SN: A60001-UP-UP

1шт.

|$10

1228 447 H91

HOUSING ASSEMBLY - LEVER

SN: A60001-UP-UP

1шт.

8

213 262 R1

RING, RETAINING

SN: A60001-UP-UP

1шт.

9

NSS

HOUSING, LEVER

SN: A60001-UP-UP

1шт.

10

1211 285 H1

SEAL, OIL

SN: A60001-UP-UP

1шт.

11

1211 286 H1

WASHER - BRAKE

SN: A60001-UP-UP

1шт.

12

355 967 R1

O-RING

SN: A60001-UP-UP

1шт.

13

352 219 R1

O-RING

SN: A60001-UP-UP

1шт.

14

1211 152 H1

SHAFT - SHIFT LEVER

SN: A60001-UP-UP

1шт.

15

NSS

LEVER, SHIFT

SN: A60001-UP-UP

1шт.

16

NSS

WICK - LEVER HOUSING

SN: A60001-UP-UP

1шт.

17

NSS

PLUG, WICK

SN: A60001-UP-UP

1шт.

18

NSS

BUSHING - LEVER HOUSING

SN: A60001-UP-UP

1шт.

19

22 411 R1

O-RING - BETWEEN HOUSINGS

SN: A60001-UP-UP

1шт.

20

NSS

O-RING - SOLENOID SWITCH

SN: A60001-UP-UP

1шт.

21

1211 356 H1

WASHER, SPACER

SN: A60001-UP-UP

1шт.

22

1211 282 H1

CABLE - SOLENOID TO END FRAME

SN: A60001-UP-UP

1шт.

|$26

120 217

WASHER, LOCK AT SOLENOID SWITCH

SN: A60001-UP-UP

1шт.

|$27

115 999

NUT, HEX AT SOLENOID SWITCH

SN: A60001-UP-UP

1шт.

|$28

120 396

WASHER, FLAT AT END FRAME

SN: A60001-UP-UP

1шт.

|$29

NSS

WASHER, LOCK AT END FRAME

SN: A60001-UP-UP

1шт.

|$30

25 526 R1

NUT, HEX AT END FRAME

SN: A60001-UP-UP

1шт.

|$31

1211 267 H1

NUT AND WASHER AT END FRAME

SN: A60001-UP-UP

1шт.

23

1228 450 H1

PLUNGER - SHIFT LEVER

SN: A60001-UP-UP

1шт.

24

1210 070 H1

WASHER - PLUNGER

SN: A60001-UP-UP

1шт.

25

1210 071 H1

BOOT - PLUNGER

SN: A60001-UP-UP

1шт.

26

1210 072 H1

RETAINER - SPRING

SN: A60001-UP-UP

1шт.

27

1210 073 H1

SPRING, PLUNGER

SN: A60001-UP-UP

1шт.

28

1210 074 H1

RETAINER, SPRING

SN: A60001-UP-UP

1шт.

29

213 262 R1

RING, RETAINER

SN: A60001-UP-UP

1шт.

30

19 839 R1

NUT, LOCK PLUNGER

SN: A60001-UP-UP

1шт.

31

1228 449 H1

SWITCH - SOLENOID

SN: A60001-UP-UP

1шт.

N/I

1210 069 H1

BOLT - MOUNTING

SN: A60001-UP-UP

3шт.

32

1211 271 H1

INSULATOR

SN: A60001-UP-UP

1шт.

33

1211 263 H1

POLE, SHOE

SN: A60001-UP-UP

4шт.

34

1211 150 H1

SCREW - POLE SHOE

SN: A60001-UP-UP

8шт.

35

1228 453 H1

INSULATOR - FIELD COIL

SN: A60001-UP-UP

1шт.

36

1210 061 H1

INSULATOR INSIDE FRAME

SN: A60001-UP-UP

1шт.

37

1210 062 H1

INSULATOR OUTSIDE FRAME

SN: A60001-UP-UP

1шт.

38

1228 452 H1

CONNECTOR - FIELD COIL TO SOLENOID

SN: A60001-UP-UP

1шт.

|$49

1211 267 H1

NUT AND WASHER AT SOLENOID

SN: A60001-UP-UP

1шт.

|$50

NSS

BOLT, MOUNTING AT FIELD COIL

SN: A60001-UP-UP

1шт.

|$51

120 385

WASHER, FLAT AT FIELD COIL

SN: A60001-UP-UP

1шт.

39

1228 454 H1

PIN, SPRING

SN: A60001-UP-UP

2шт.

40

1223 256 H1

ARMATURE

SN: A60001-UP-UP

1шт.

41

NSS

WASHER, THRUST

SN: A60001-UP-UP

1шт.

42

1228 605 H1

FIELD COIL

SN: A60001-UP-UP

1шт.

43

NSS

PLATE, BRUSH

SN: A60001-UP-UP

1шт.

|$57

1223 263 H1

SCREW AND WASHER - THRU END FRAME TO PLATE

SN: A60001-UP-UP

6шт.

|$58

1211 292 H1

SCREW - FIELD COIL TO PLATE

SN: A60001-UP-UP

4шт.

44

NSS

BRUSH

SN: A60001-UP-UP

4шт.

45

NSS

SPRING, BRUSH

SN: A60001-UP-UP

4шт.

46

1223 265 H1

LEAD, TERMINAL

SN: A60001-UP-UP

1шт.

47

NSS

O-RING - BETWEEN HOUSINGS

SN: A60001-UP-UP

1шт.

48

1223 269 H91

PACKAGE - TERMINAL INSULATOR

SN: A60001-UP-UP

1шт.

|$64

1223 255 H1

HOUSING ASSEMBLY - END FRAME

SN: A60001-UP-UP

1шт.

49

NSS

HOUSING - END FRAME

SN: A60001-UP-UP

1шт.

50

NSS

WICK, OIL

SN: A60001-UP-UP

1шт.

51

NSS

PLUG, WICK

SN: A60001-UP-UP

1шт.

52

NSS

BUSHING - END FRAME

SN: A60001-UP-UP

1шт.

53

1210 066 H1

PLUG, INSPECTION

SN: A60001-UP-UP

1шт.

54

1211 151 H1

GASKET, INSPECTION PLUG

SN: A60001-UP-UP

1шт.

|$71

1223 266 H91

PACKAGE, BUSHING

SN: A60001-UP-UP

1шт.

|$72

1223 367 H91

PACKAGE, SHIFT LEVER

SN: A60001-UP-UP

1шт.

|$73

1223 268 H91

PACKAGE, BRUSH

SN: A60001-UP-UP

1шт.

|$74

-1шт.

|$75

F1 - PART OF BUSHING PACKAGE P/N 1223 266 H91.

-1шт.

|$77

-1шт.

|$78

F2 - PART OF BUSHING PACKAGE P/N 1223 267 H91.

-1шт.

|$79

-1шт.

|$84

F3 - PART OF BRUSH PACKAGE P/N 1223 268 H91.

-1шт.

|$80

-1шт.

|$81

F4 - PART OF BUSHING PACKAGE P/N 1223 266 H91 AND PART OF BUSHING PACKAGE P/N 1223 267 H91.

-1шт.

|$86

-1шт.

|$87

F5 - PART OF BUSHING PACKAGE P/N 1223 266 H91 AND PART OF BRUSH PACKAGE P/N 1223 268 H91.

-1шт.

|$88

-1шт.
